Pioneer fxm 2017 service manual

Page 1

Pioneer sound. vision. soul

Service
Manual

1 2 I] lanai
:filna
0- -°

ORDER NO.

I CRT2741

HEAD UNITI3 in 1)

FX-MEO17ZSA m...

I ICDMPACT
DIGITAL AUDIO

VEHICLE DESTINATION PRODUCED AFTER SAAB PART No. ID No. PIONEER MODEL No.
SAAB 9»5 EUROPE 2001 5038120 FX»M2017ZSA/X1B/EW

. This service manual should be used together with the following manual(s):

Model No. Order No. Mech. Module Remarks
CX»1011 CRT2406 3L Cassette Mech. ModulezMechDescription, Disassembly
CX-958 CRT2423 88.1 CD Mech. ModulezCircuit Description, Mech.Description, Disassembly

. Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.

"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.

CONTENTS
1. SAFETY INFORMATION ................... 7.1.2 DISASSEMBLY
2. EXPLODED VIEWS AND PARTS LIST.. .. 7.1.3 PCB LOCATIONS.
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ...10 7.1.4 CONNECTOR FUNCTION DESCRIPTION71
4. PCB CONNECTION DIAGRAM 7.2 IC
5. ELECTRICAL PARTS LIST ....... 7.3 EXPLANATION.
6. ADJUSTMENT .......................................................... 58 7.3.1 OPERATIONAL FLOW CHART ................. 78
7. GENERAL INFORMATION 7.3.2 SYSTEM BLOCK DIAGRAM....
7.1 DIAGNOSIS ................. 7.3.3 JIG CONNECTION DIAGRAM.
7.1.1 TEST MODE .............................................. 64 8. OPERATIONS AND SPECIFICATIONS ..................... 80
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan

PIONEER ELECTRONICS (USA) INC. ROBox 1760, Long Beach, CA 908014760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #0401, Singapore 159936

© PIONEER CORPORATION 2001 K-ZZV. AUG. 2001 Printed in Japan

Page 2

FX-MEO17ZSA

. CD Player Service Precautions

1. For pickup unit(CXX1285) handling, please refer 2. During disassembly, be sure to turn the power off
to"Disassembly"(see page 65). since an internal IC might be destroyed when a con»
During replacement, handling precautions shall be nector is plugged or unplugged.
taken to prevent an electrostatic dischargelprotection 3. Please checking the grating after changing the ser-
by a short pin). Vice pickup unit(see page 62).

1. SAFETY INFORMATION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.

1. Safety Precautions for those who Service this Unit.
. When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable

results.

Caution:
1. During repair or tests, minimum distance of 13cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.

2. A "CLASS 1 LASER PRODUCT" label is affixed to the 3. The triangular label is attached to the mechanism
top of the Case. unit frame.

CLASS 1
LASER PRODUCT

4. Specifications of Laser Diode

Specifications of laser radiation fields to which human access is possible during service.
Wavelength = 800 nanometers
