FM/AM DIGITAL SYNTHESIZER TUNER

Opera ting

Ins truc tionS

I 6 I'
o :iillillllllllllllllllilll fijtfl ,.."'"-'

PO". L

uuuuuuuuuuuuuuuuuu F- )I '-
31:, B 3.5, 8 :2: 33m Tiff?
" 1m

593.» .Vru- 4.4.... . 7:; ii CE

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will know how to operate your model
properly. After you have finished reading the instructions, put them away in a safe place for
future reference.

In some countries or regions, the shape of the power plug may sometimes differ from that
shown in the explanatory drawings. However, the method of connecting and operating the
unit is the same.

WARNING: TO pnevem FIRE on suocx - LINE VOLTAGE SELECTOR SWITCH

HAZARD, DO NOT EXPOSE THIS APPLIANCE T0 RAIN Only multi-voltage models are provided with this switch.

OR MOISTURE. U.S., Canadian, European, U.K., and Australian models
are not provided with this switch. Mains voltages in Saudi

IMPORTANT NOTICE Arabia are 127V and 220V only. Never use this model with

[For U.S. and Canadian models] 110V setting in Saudi Arabia-

You will find the line voltage selector switch on the rear panel.
Before your model is shipped from the factory, the switch is
set to the power requirements of the destination; nevertheless,
you should check that it is set'properly before plugging the
power cord into the AC outlet. If the voltage is not properly set,
[For Canadian model] or if you move to an area where the voltage requirements differ,
adjust the selector switch as follows. Before adjusting,
disconnect the power cord.

The serial number for this equipment is located on the
rear panel. Please write this serial number on your
enclosed warranty card and keep it in a secure area. This
is for your security.

CAUTION: TO PREVENT ELECTRIC SHOCK DO

NOT USE THIS (POLARIZED) PLUG WITH AN EXTENSION 1. Provide yourself with a medium-size screwdriver.
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE 2. Using the screwdriver turn until the arrow points to the
BLADES CAN BE FULLY INSERTED TO PREVENT BLADE voltage level of your area.
EXPOSURE.

- . 120~127V
ATTENTION. POUR PREVENIR LES CHOCS

ELECTRIOUES EN PAS UTILISER CETTE FICHE
POLARISEE AVEC UN PROLONGATEUR UNE PRISE DE
COURANT ou UNE AUTRE SORTIE DE COURANT, SAUF
SI LES LAMES PEUVENT ETRE INSEREES A FOND SANS mv

EN LAISSER AUCUNE PARTIE A OECOUVERT. Lmmm

Medium-Size screwdriver

GI) PIONEER"

The future oi sound and vision.

Page 2

SAFETY INSTRUCTIONS

READ INSTRUCTIONS - All the safety and
operating instructions should be read before the
appliance is operated.

RETAIN INSTRUCTIONS - The operating instruc-
tions should be retained for future reference.
HEED WARNING - All warnings on the appliance
and in the operating instructions should be

adhered to.

FOLLOW INSTRUCTIONS - All operating and use
instructions should be followed.

WATER AND MOISTURE - The appliance should
not be used near water - for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool, etc.

LOCATION - The appliance should be installed in a
stable location.

WALL OR CEILING MOUNTING - The appliance
should not be mounted to a wall or ceiling.

POWER LINES-An outdoor antenna should be
located away from power lines.

NONUSE PERIODS --The power cord of the
appliance should be unplugged from the outlet
when left unused for a long period of time.

OBJECT AND LIQUID ENTRY- Care should be
taken so that objects do not fall and liquids are
not spilled into the enclosure through openings.

DAMAGE REQUIRING SERVICE - The appliance
should be serviced by a Pioneer authorized ser-
vice center or qualified service personnel when:

0 The power-supply cord or the plug has been
damaged; or

0 Objects have fallen, or liquid has been spilled into
the appliance; or

O The appliance has been exposed to rain; or

0 The appliance does not appear to operate nor-
mally or exhibits a marked change in perfor-

VENTILATION ~ The appliance should be situated mance; or
so that its location or position does not interfere O The appliance has been dropped; or the enclosure
with its proper ventilation. For example, the ap- damaged.

pliance should not be situated on a bed. sofa, rug.
or similar surface that may block the ventilation
openings; or, placed in a built-in installation, such
as a bookcase or cabinet that may impede the
flow of air through the ventilation openings.

HEAT - The appliance should be situated away from
heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers)
that produce heat.

POWER SOURCES - The appliance should be
connected to a power supply only Of the type
described in the operating instructions or as
marked on the appliance.

POWER-CORD PROTECTION - Power-supply
cords should be routed so that they are not likely
to be walked on or pinched by items placed upon
or against them, paying particular attention to
cords at plugs, convenience receptacles, and the
point where they exit from the appliance.

POLARIZATION - If your purchased product is

SERVICING-The user should not attempt to
service the appliance beyond that described in the
operating instructions. For all other servicing,
contact the nearest Pioneer authorized service
center.

POWER LINES

SERVICE ,.
ENTRANCE
CONDUCTORS. @

ii MAST

ROUND
LAMP

G
C

\X

OUTDOOR ANTENNA GROUNDING - If an out-

side antenna is connected to the antenna termi-
nal, be sure the antenna system is grounded so as
to provide some protection against voltage surges
and built up static charges.
In the USA. section 810 of the National Elec-
trical Code, ANSI/NFPA NO. 70-1984, provides
information with respect to proper grounding of
the mast and supporting structure, grounding of
the lead-in wire to an antenna discharge unit. size
of grounding conductors, location Of antenna-
discharge unit, connection to grounding elec-
trodes, and requirements for the grounding elec-
trode. See Fig. A.

3) Use No.10 AWG (5.3 mmz) cop-
per, No. 8 AWG (8.4 mmz) alu-
minum, No. 17 AWG (1.0 mm?)
copperclad steel, bronze wire, or
larger as ground wire.

b) Secure antenna lead-in and
ground wires to house with
stand-Off insulators spaced from
4 feet (1.22 meters) to 6 feet
(1.83 meters) apart.

C) Mount antenna discharge unit as

closely as possible to where lead-

in enters house.

Use jumper wire not smaller than

No.6 AWG (13.3 mmz) copper.

or the equivalent, when a sepa-

rate antenna-grounding electrode
is used.

STAND-OFF d)
INSULATORS b

See NEC Section 810-21 (j).

provided with a polarized power plug, please read ANTENNA
the following instructions. This product is w I 3" WI
equipped with a polarized alternating current line " TO EXTERNAL ANTENNA

TERMINALS OF PRODUCT

plug (a plug having one blade wider than the
other). This plug will fit into the power outlet only

0

GROUND

' ' GROUND WIRE a.b ANTENNA

one way. This IS a safety feature. If you are unable SERVICE ENTRANCE ,. CLAMPS DISCHARGE UNIT c
to Insert the plug fully Into the outlet, try reverSIng EQUIPMENT GROUND
the plug. If the plug should still fail to fit, contact WIRE a.b
your electrician to replace your obsolete outlet.
Do not defeat the safet ur ose of the olarized

| y p p p \ M GROUND
p 9 POWER SERVICE 1; CLAMPS

r

I
K r OPTIONAL ANTENNA
.l, GROUNDING ELECTRODE

DRIVEN e EEET (2.44 m)
BONDING - INTO THE EARTH
JUMPER d II IF REQUIRED BY
FIG.A u LOCAL CODES SEE
NEC SECTION 31021 (f).

CLEANING - The appliance should be cleaned only
with a polishing cloth or a soft dry Cloth. Never
Clean with furniture wax, benzine, insecticides or
other volatile liquids since they may corrode the
cabinet.

GROUNDING ELECTRODE SYSTEM
(e.g. Interior metal water pipe)

IM PORTANT1

RISK OF ELECTRIC SHOCK
DO NOT OPEN

2

The lightning flash with arrowhead, within an equi-
lateral triangle, is intended to alert the user Of the
presence of uninsulated "dangerous voltage within
the product's enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.

IM PO RTANT 2

If the apparatus is fitted with AC mains power out-
Iet(s), see REAR PANEL FACILITIES for convenient
connection of additional Hi-Fi component(s). Make
all connections to the AC outlet(s) and the signal
terminals first. Connect the plug tO the wall socket
last, make sure that the power switch is off. Discon-
nect the wall plug when the equipment is not in
(regular) use, eg when on vacation.

< ARB1075 >

CAUTION:

TO PREVENT THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.

FOR USE IN THE UNITED
KINGDOM

The wires in this mains lead are coloured in accor-
dance with the following code:

Blue: Neutral

Brown: Live

The exclamation point within an equilateral triangle is
intended to alert the user of the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
marking identifying the terminals in your plug proceed
as follows:

The wire which is coloured blue must be connected to
the terminal which is marked with the letter N or
coloured black.

The wire which is coloured brown must be connected
to the terminal which is marked with the letter L or
coloured red.

Equipment sold in the U.K. is not supplied with
a power plug.
