Page: 1 / 33
pioneer dvr 505 service manual

Extracted text from pioneer dvr 505 service manual (Ocr-read)


Page 2

DVR7505(K) 1'11th 01.12.18 7:59PM «Hs/7.

/\

\/

DVR-505/7000

CONTENTS / ACCESSORIES / CAUTIONS

Contents

CONTENTS / ACCESSORIES / CAUTIONS ............. 2
BLOCK DIAGRAM ........


SCHEMATIC DIAGRAM .......................................... 16
EXPLODED VIEW ....28

....3
CIRCUIT DESCRIPTION. ...4 PARTS LIST ....... ....29
WIRING DIAGRAM .. 9 SPECIFICATIONS ...................................... Back cover
PC BOARD ...........
Accessories
r \
FM indoor antenna(1) Loop antenna(1) Video cord (1) Remote control unit (1)
(T90-0882-08) (T90-0896-08) (E30-1427-05) (A70-1580-08): KPXY
(A70-1580-08): MM2M3
(A70-1581-08): E
raagggzagghgetfl
aglfiggfigfiooaoefifll
Speaker cords (6) Batteries (LROB/AAA) (2) SCART PIUQ (1) (for UK. only)
(E30-7265-08): Red (E69-0012-05)
(E30-7266-08): Blue
(E30-7267-08): Brown \ \
(E30-7268-08): Blue 919 %I
(E30-7269-08): Gray
(E30-7270-08): Orange
AC Plug Adaptor (1)
(E03-0115-05)
,4 Use to adapt the plug on the
I power cord to the shape of the
wall outlet.
(Accessory only for regions where
use is necessary.)
\ )
Cautions

Operation to reset

The microcomputer may fall into malfunction (impossibility to
operate, erroneous display, etc.) when the power cord is un-
plugged while power is ON or due to an external factor. In this
case, execute the following procedure to reset the microcom-
puter and return it to normal condition.

Set the POWER switch to ON (set to Standby
mode). Then press the m key, H4 key and STOP
key in this order.

0 Please note that resetting the microcomputer clears the

contents stored in and returns and to condition when it left
the factory.

The marking of products using lasers System configuration

(Except for some 3,935, SYSTEM MAIN UNIT DESTINATION SPEAKER

KS-305DV

DVT-505 DVR-505 KP SW-15DV

The marking this product has been classified as Class DVTJOOO DVRJOOO ETMXY KSWJOOO

1. It means that there is no danger of hazardous radiar DVT'7OOO(M2I DVRJOOOIMZ) M2 KSWJOOO

tion outside the product. DVT-7000(M3) DVR-7000(M3) M3 KSW-7000
Location: Back panel
