Pioneer dvr 225 s service manual
This is the 75 pages manual for pioneer dvr 225 s service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer dvr 225 s service manual (Ocr-read)
Page 1
Page 2
Contents Overview 4 M od el Num ber Setting 26 Block Di agrams 5~9 D isc Download Procedure 27~28 Recording Block 6~7 Service M odes 29~51 Preview Block 8~9 Service M ode Screens 29~35 Overall Board Layout 10 Error Codes 36~39 Main Board 11~12 Key Codes 40~42 HDD Unit 13 Sim ple DV Diagnosis 43 Overall Block Diagrams 14~17 Error Rate Measurements 44~45 System Co nfiguration 15 Channel Setting Mode 46~49 Com plete Block 16~17 Aging Modes 50~51 Adjustments & Data Setting Modes 18~52 Start -Up Sequence 52 Tuner & Main PCB Adjustments 19~20 D isasse mbl y Se ction 53~58 Service Diagnosis List 21 LSI_NG & Flash_NG Diagnosis 60~66 CPRM ID Num ber & Data Setti ng 22~25 HDD Diagnosis Method 68~74
