Pioneer sound. I/I'sion.soul

Service
Manual

ORDER NO.

CRT3051

MULTI-CD/DAB CONTROL HIGH POWER CD/MP3/WMA PLAYER WITH RDS TUNER

DEH-P7500MPW

. This service manual should be used too

ether with the following manual(s):

Model No.

Order No.

Mech. Module

Remarks

CX»3057

CRT3026

S10MP3

CD Mech. Module:Circuit Description, MechDescription, Disassembly

[IQ-I

For details, refer to Important symbols for good services".

PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC.

4-1, Meguro 1-Chome, Meguro»ku, Tokyo 153-8654, Japan
P.O.Box1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV Haven 1087 Keetberglaan II 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #0401, Singapore 159936

© PIONEER CORPORATION 2003

K-ZZD. APR. 2003 Printed in Japan

Page 2

[ Important symbols for good senlioes ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely,
When you find the procedures bearing any of the symbols, be sure to fulfill them:

1. Product safety

You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during sen/icing by following the safety instructions described in this manual.

N

. Adjustments

To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.

3. Cleaning

. o For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
% proper cleaning should be performed to restore their performances.

4. Shipping mode and shipping screws \

To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.

5. Lubricants, glues, and replacement parts

Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying

glue may lead to failures or troubles in the product By following the instructions in this manual, be sure to apply the

g prescribed grease or glue to proper portions by the appropriate amount.For replacement pans or tools, the prescribed
ones should be used.
