Pioneer DEH 24UB Owners Manual
This is the 56 pages manual for Pioneer DEH 24UB Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Pioneer DEH 24UB Owners Manual (Ocr-read)
Page 1
Thank youfor purchasing this PIONEER product To ensure proper use, please read through this manual before using this product. It is especially important that you read and observe WARN- ING s and CAUTION s in this manual. Please keep the manual in a safe and accessible place for future reference. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interfer- ence, and (2) this device must accept any in- terference received, including interference that may cause undesired operation. Information to User Alteration or modifications carried out with- out appropriate authorization may invalidate the user s right to operate the equipment. Note This equipment has been tested and found to comply with the limits for a Class B digital de- vice, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in- stalled and used in accordance with the instruc- tions, may cause harmful interference to radio communications. However, there is no guaran- tee that interference will not occur in a particu- lar installation. If this equipment does cause harmful interference to radio or television recep- tion, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equip- ment and receiver. - Connect the equipment into an outlet on a cir- cuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. The Safety of Your Ears is in Your Hands Get the most out of your equipment by playing it at a safe level -a level that lets the sound come through clearly without annoying blaring or dis- tortion and, most importantly, without affecting your sensitive hearing. Sound can be deceiving. Over time, your hearing comfort level adapts to higher volumes of sound, so what sounds nor- mal can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. ESTABLISH A SAFE LEVEL:! Set your volume control at a low setting. ! Slowly increase the sound until you can hear it comfortably and clearly, without distortion. ! Once you have established a comfortable sound level, set the dial and leave it there. BE SURE TO OBSERVE THE FOLLOWING GUIDELINES: !Do not turn up the volume so high that you can t hear what s around you. ! Use caution or temporarily discontinue use in potentially hazardous situations. ! Do not use headphones while operating a motorized vehicle; the use of headphones may create a traffic hazard and is illegal in many areas. About this unit The tuner frequencies on this unit are allocated for use in North America. Use in other areas may result in poor reception. WARNING Handling the cord on this product or cords asso- ciated with accessories sold with the product may expose you to chemicals listed on proposi- tion 65 known to the State of California and other governmental entities to cause cancer and birth defect or other reproductive harm. Wash hands after handling. CAUTION: USE OF CONTROL OR ADJUSTMENT OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. CAUTION: THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD. CAUTION ! Do not allow this unit to come into contact with liquids. Electrical shock could result. Also, damage to this unit, smoke, and over- heating could result from contact with liquids. ! Always keep the volume low enough to hear outside sounds. ! Avoid exposure to moisture. ! If the battery is disconnected or discharged, any preset memory will be erased. Important (Serial number) The serial number is located on the bottom of this unit. For your own security and conven- ience, be sure to record this number on the en- closed warranty card. Note Function setting operations are completed even if the menu is cancelled before the operations are confirmed. About this manual ! In the following instructions, USB memories and USB audio players are collectively re- ferred to as USB storage device . ! In this manual, iPod and iPhone will be re- ferred to as iPod . Demo mode Important ! Failure to connect the red lead (ACC) of this unit to a terminal coupled with ignition switch on/off operations may lead to battery drain. ! Remember that if the feature demo contin- ues operating when the car engine is turned off, it may drain battery power. The demo starts automatically if you do not oper- ate this unit within about 30 seconds since the unit was last operated or if the ignition switch is set to ACC or ON while the unit is turned off. To cancel the demo mode, you need to display the initial settings. Select DEMO(demo display set- ting) and turn off the demo display. For details, refer to Initial settings on page 9. Before you start 2 Section Before you start En 01
Page 2
After-sales service for Pioneer products Please contact the dealer or distributor from where you purchased this unit for after-sales service (including warranty conditions) or any other information. In case the necessary infor- mation is not available, please contact the com- panies listed below: Please do not ship your unit to the companies at the addresses listed below for repair without ad- vance contact.U.S.A. Pioneer Electronics (USA) Inc. CUSTOMER SUPPORT DIVISION P.O. Box 1760 Long Beach, CA 90801-1760 800-421-1404 CANADA Pioneer Electronics of Canada, Inc. CUSTOMER SATISFACTION DEPARTMENT 340 Ferrier Street Unit 2 Markham, Ontario L3R 2Z5, Canada 1-877-283-5901 905-479-4411 For warranty information please see the Limited Warranty sheet included with this unit. In case of trouble Should this unit fail to operate properly, please contact your dealer or nearest authorized PIONEER Service Station. Visit our website http://www.pioneerelectronics.com in Canada http://www.pioneerelectronics.ca ! Learn about product updates (such as firm- ware updates) for your product. ! Register your product to receive notices about product updates and to safeguard pur- chase details in our files in the event of loss or theft. ! Access owner s manuals, spare parts infor- mation, service information, and much more. Head unit DEH-3400UB and DEH-34UB b cde a 87 12 34 5 6 9 Part Part 1 h(eject) 8 (back/display) 2 (list) 9c/d 3 MULTI-CONTROL ( M.C. ) aBAND / (iPod control) 4 SRC/OFF b1to 6 5 Disc loading slot c (clock) 6 USB port dAUX input jack (3.5 mm stereo jack) 7 (color) eDetach button DEH-2400UB and DEH-24UB b cde a 87 12 34 5 6 9 Part Part 1 h(eject) 8 (back/display) 2 (list) 9c/d Part Part 3 MULTI-CONTROL ( M.C. ) aBAND / (iPod control) 4 SRC/OFF b1to 6 5 Disc loading slot c (clock) 6 USB port dAUX input jack (3.5 mm stereo jack) 7 e Detach button CAUTION !Use an optional Pioneer USB cable (CD- U50E) to connect the USB audio player/USB memory as any device connected directly to the unit will protrude out from the unit and may be dangerous. ! Do not use unauthorized products. Remote control f j i gh k aml 9 4 Part Operation f VOLUME Press to increase or decrease volume. g MUTE Press to mute. Press again to unmute. English Before you start 3 Section Operating this unit En 01 02
