GD PIONEEIT

Theiumof sound and vision.

ORDER NO.
ARP1688
STEREO DOUBLE CASSETTE TAPE DECK AMPLIFIER
MODEL DC-282 HAS SIX VERSIONS:
Type Power requirement Expert destination
HB Ac220V.1l0V(swithcable)- United Kingdom
HE ' ACZZOV,24OV(swithcab|e)- European continent
HEZ ACZZDV.240V(swi(hcabla)- Wesl Germany
SD AC110V,120V-127v.220v,240V(swithcable) Kingdom of SaudiArahia and general market
YP ACMOV anly Australia
KU ACIZOV only U.S.A.

-Chunge The jumper wires 0! assembly boards.

eThis manual is applicable to the DC-ZBZ/HB and HE types.

oFor HE type,reler to pages 81-82.

a For the other types,refer to additional service manuals.

oCe manual pour le service comprend les explications en frangais de réglage.
oEsle manual de servicio trata del métode ajuste escrito en espafiolv

CONTENTS

1.SAFETY INFORMATION ................. 2 6.ADJUSTMENTS .I: .............................. 59

2.P.C.BOARDS LOCATION .................. '3 REGLAGE .......................................... 64

3.EXPLODED VIEWS,PACKING AJUSTE 59
AND PARTS LIST .............................. 6 7.IC INFORMATION ........................... 74

4.SCHEMATIC DIAGRAM AND 8.FOR HE TYPES ------------------------- 81
P.C.BOARDS CONNECTION 9.CONNECTIONS --------------------------------- 83
DIAGRAM .......................................... 18 10.PANEL FACILITIES

5.ELECTRICAL PARTS LIST --------- 53 SPECIFICATIONS --------------------------- 89

PIONEER ELECTRONIC CORPORATION 4-1,Meguro rename, Meguro-ku, Tokyo 153. Japan

PIOIEER WSERVICE INC. ROI Box 1750. Long Beach. California 90801 USA.

PIONEER EECTRONICS OF CANADA, INC. 505 Cochrane Drive. Markham, Ontario L3H 8E3 Canada

PIONEER ELECTRONIC [EUROPE] NM Keelberglaan 1, 2740 Beveren, Belgium

PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178-184 Boundary Road. Braaide, Victoria 3195. Australia TEL: [03] 580-9911

9 PIONEER ELECTRONIC CORPORATION 1983 _ Yv JANJQBQ Primed In Japan.

Page 2

1. SAFETY INFORMATION

1. SAFETY PRECAUTIONS
The following check should be performed for the
continued protection of the customer and service tech-
nician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground
(water pipe, conduit, etc.) by connecting a leakage current
tester such as Simpson Model 229-2 or equivalent between
V the earth ground and all exposed metal parts of the appli-
ance (input/output terminals, screwheads, metal overlays,
control shaft, eth. Plug the AC line cord of the appliance
directly into I 120V AC 60Hz outlet and turn the AC
power switch on. Any current measured must not exceed
0.5mA.

Reading should
not be above
0.5mA

Test all

exposed rrtetal

suriaces

Zwrre cord

@ Alto test with
plug reverwd
(Using AC adapter
plug as required)

Earth
ground

AC Leakage Test

ANY MEASUREMENTS nor WITHIN THE LIMITS
ouereo move an: INDICATIVE or A P0
TENTIAL suocx HAZARD AND MUST as con-
necreo eerone- RETURNING me APPLIANCE
to THE cusrouen. '

2. PRODUCT SAFETY NOTICE

Many electrical and mechanical parts in the appliance
have special safety related characteristics. These are often
not evident irom visual inspection nor the protection
afforded by them necessarily can be obtained by using
replacement components rated for voltage, wattage, etc.
Replacement pans which have these special safety charac-
teristics are identified in this Service Manual.

Electrical components having such features are identified

by marking with ari on the schematics and on the pans
list in this Service Manual.
The use of a substitute replacement component which
dose not have the same safety characteristics as the
PIONEER recommended replacement one, shown in the
parts list in this Service Manual, may create shock, fire,
or other hazards.

Product Safety is continuously under review and new
instructions are issued from time to time. For the latest
information, always consult the current PIONEER Service
Manual. A subscription to, or additional copies of, PIONEER
Service Manual may be obtained at a nominal charge from
PIONEER.
