Pioneer cx 3195 service manual
This is the 27 pages manual for pioneer cx 3195 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer cx 3195 service manual (Ocr-read)
Page 1
CX-3195 2 1234 1234 C D F A B E CONTENTS 1. CIRCUIT DESCRIPTIONS ............................................................................................................................... 3 2. MECHANISM DESCRIPTIONS ...................................................................................................................... 20 3. DISASSEMBLY .............................................................................................................................................. 22
Page 2
CX-3195 3 5 678 567 8 C D F A B E 1. CIRCUIT DESCRIPTIONS V850ES core BMC EFM decoder 1bit DAC Internal RAM (1Mbit)PE5547A Port controlAudio DSP CIRC PORT I/F SRAM Analog output RF amplifier CD-ROM decoder Digital servoA,B,E,F Signal The recent mainstay of the CD LSI is the LSI integrating the core DSP with DAC or RF amplifier, which are generally employed as peripheral circuits, however, PE5547A, used in this product, is an LSI integrating the afore-mentioned LSI unit and microcomputer unit in one chip. Fig.1.0.1 Block diagram of CD LSI PE5547A
