STEREO DOUBLE CASSETTE DECK

CT-WéEOR
CT-WSSO

canons-a: n-umwcr-wasok I .1.

.- n ammo-n mam

Thank you for buying this PIONEER product.

Please read through these operating instructions so you will
know how to operate your unit properly. After you have finished
reading the instructions, keep the manual in a safe place for
future reference.

In some countries or regions, the shape of the power plug and
power outlet may sometimes differ from that shown in the ex-
planatory drawings. However, the method of connecting and
operating the unit is the same.

WARNING: To PREVENT FIRE on SHOCK HAZ-
ArID, D0 NoT EXPOSE THIS APPLIANCE To ilAlN on
MOISTURE.

IMPORTANT NOTICE

The serial number for this equipment is located on the rear panel.
Please write this serial number on your enclosed warranty card
and keep it in a secure area. This is for your security.

[For Canadian model]

This digital apparatus does not exceed the Class B limits for
radio noise emissions from digital apparatus set out in the Ra-
dio Interference Regulations of the Canadian Department of
Communications.

[Pour le modéle Canadian]

Linterférence, radioélectrique générée per set appareil nu-
mérique de type B ne dépasse pas les Iimites énoncées dans
le Réglement sur les perturbations radioélectriques, section
appareil numérique, du Ministers des Communications.

This product complies with the Radio Interference require-
ments of the EC {European Community) Directive 87/308/EEC.

l The illustration shows model CT-WSSOR.

| LINE VOLTAGE SELECTOR SWITCH l

Medium-size
screwdriver

Only multi-voltage models are provided with this switch.
u.s., Canadian, European, U.K., and Australian models are not
with provided this switch.

Mains voltages in Saudi Arabia are 127V and 220V only.
Never use this model with a 1 1 0V setting in Saudi Arabia.
The line voltage selector switch is on the rear panel. Before your
model is shipped from'the factory, this switch is set to the power
requirements of the destination. Make sure that it is set properly
before plugging the power cord into the AC outlet If the voltage
is not properly set, or if you move to an area where the voltage re-
quirements differ. adjust the selector switch as follows.

1 . Disconnect the power cord.

2. Use a medium-size screwdriver.

3. Insert the screwdriver into the groove on the voltage selector.
and adjust so that the tip of the arrow points to the voltage
value for your area.

IMPORTANT 1

The lightning tlash with arrowhead, within an equilateral CAUTION:
triangle, is intended to alert the user In the presence al
uninsulated "dangerous voltage within the ploducls
enclosure that may be or suflicient magnitude to constitute
a risk at electric shock in persons.

CAUTION

RISK OF ELECTRIC SHOCK
DO NOT OPEN

TO PREVENT THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE COVER (0H BACK). NO USERV
SERVICEABLE PARTS INSIDE. REFER SERVICING T0
QUALIFIED SERVICE PERSONNEL.

The exclamation pninr wirnin an equilateral triangle is
intended to alert me user to the presence or important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.

(U) mom-zen
