STEREO DOUBLE CASSETTE DECK

T-W3DO

Met:

-a «.2. comm:

Thank you for buying this Pioneer product.

Please read throughthese operating instructions so you will
know how to operate your model properly. After you have
finished reading the instructions, put them away in a safe
place for future reference.

In some countries or regions, the shape of the power plug
and power outlet may sometimes differ from that shown
in the explanatory drawings. However, the method of
connecting and operating the unit is the same.

WARNING: TO PREVENT FIRE on SHOCK

HAZARD. DO NOT EXPOSE THIS APPLIANCE T0 RAIN 0R
MOISTURE.

IMPORTANT NOTICE

[For U.S. and Canadian models]

The serial number for this equipment is located on the rear
panel. Please write this serial number on your enclosed
warranty card and keep in a secure area. This is for your
security.

LINE VOLTAGE SELECTOR SWITCH

Only multi-voltage models are provided with this switch.
U.S., Canadian, European, U.K., and Australian models are
not provided with this switch.

Main voltages in Saudi Arabia are 127V and 220V only.
Never use this model with 1 10V setting in Saudi Arabia.

The line voltage selector switch is on the rear panel. Before
your model is shipped from the factory, this switch is set
to the power requirements of the destination. Check that
it is set properly before plugging the power cord into the
AC outlet. If the voltage is not properly set or if you move
to an area where the voltage requirements differ,adjust the
selector switch as follows.

1. Disconnect the power cord.

2. Use a medium-size screwdriver.

3. Insert the screwdriver into the groove on the voltage
selector, and adjust so that the tip of the arrow points
to the voltage value of your area.

v

Volts

/

Medium-size screwdriver

This product is manufactured to comply with the radio
interference requirements of EEO Directive 76/889/EEC
and 32/499/EEC."
