Opera ting

Ins truc tions

STEREO CASSETTE DECK

r

33.33

... Gnu-II-nnuh'niu

=t>oo=igm egg

Thank you for buying this Pioneer product

Please read through these operating instructions to learn how to operate
your model properly. After you have finished reading the instructions, put
them away in a safe place for future reference.

In some countries or regions. the shape of the power plug and power
outlet may differ from that shown in the explanatory drawings. However,
the method of connecting and operating the unit is the same.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD.
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.

IMPORTANT NOTICE

[For us. and Canadian models]

The serial number for this equipment is located on the rear panel. Please
write your serial number on your enclosed warranty card and keep it in a
secure area. This is for your security.

[For Canadian model]

CAUTIONzro PREVENT ELECTRIC SHOCK DO
NOT USE THIs (POLARIZED) PLUG WITH AN EXTENSION
CORD. RECEPTACLE OR OTHER OUTLET UNLEss THE
BLADEs CAN BE FULLY INsERTED TO PREVENT BLADE
EXPOSURE.

ATTENTION:POUR PREVENIR LES CHocs

ELECTRIOUES NE PAS UTILISER CETI'E FICHE POLARISEE
AVEC UN PROLONGATEUR UNE PRISE DE COURANT OU
UNE AUTRE SORTIE DE COURANT. SAUF SI LES LAMES
PEUVENT ETRE INSEREES A FOND SANS EN LAISSER
AUCUNE PARTIE A DECOUVERT.

The illustration shims CT -S705.

LINE VOLTAGE SELECTOR SWITCH

Only mum-voltage models are provided with this switch.

0.8., Canadian, European. U.K.. and Australian models are not provid-
ed with this switch.

Main voltages in Saudi Arabia are 1 27V and 220V only.

Never use this model with 1 10V setting in Saudi Arabia.

The line voltage selector switch is on the rear panel. Before shipping your

model from the factory. this switch has been set to the power require-

ments of the destination. Check that it has been pTOperly set before plug-

ging the power cord into the AC outlet. If the voltage is not properly set

or if you move to an area where the voltage requirements differ. adjust

the selector switch as follows.

1. Disconnect the power cord.

2. Insert a medium-sized screwdriver into the groove on the voltage
selector.

3. Adjust the voltage selector sothat the tip of the arrow points to your
required voltage value.

Medium-size screwdriver

This product is manufactured to comply with the radio interference

requirements of EEC Directive 76/889/EE C and 82/499/EE .

(1.9 PIONEER

The future oi sound and Vision.
