Operating

Instructions

0 Side panels not supplied with
Europe and U.K. models.

o Photograph shows BLACK
finished models.

Thank you for buying this Pioneer product.

Please read these operating instructions thoroughly, so you will know
how to operate your model properly. After you have finished reading
the instructions, put them away in a safe place for future reference.
For the sake of convenience, these operating instructions are based
on the model HEM, and they can be used for the HB, HP, KU, KC, D
and BIG models.

The differences between the models are given below.

HEM model:
For Europe excluding U.K. ('HEM' stamped on packing case): Power
line voltage is AC 220 volts.

HB model:
For U.K. ('HB stamped on packing case): Power line voltage is AC
240 volts.

HP model:
For Australia (HP' stamped on packing case): Power line voltage is
AC 240 volts.

KU and KC models:
For U.S.A. and Canada ('KU or KC' stamped on packing case):
Power line voltage is AC 120 volts.

D and DIG models:

For destinations excluding above ('0 or D/G' stamped on packing
case): A 3-point (120 V/220 V/24O Vi voltage selector switch is pro-
vided.

NOTE:
Depending upon the model, the design of the power plug and the
power outlet differs.
.
The line voltage selector switch is located on the rear panel of
the unit. Please check that it is set properly before plugging the
power cord into an outlet. If it is not set properly, chanye the
setting of it according to the LINE VOLTAGE SELECT/0N
l0 and 0/6 models only).

Features ...................... .. .................... .
About the Accessory Wood~Grain Side Panels
Rear Panel Facilities and Connections ........
Front Panel Facilities ................
Recording ................
AUTO BLE Tuning System .
Playback .................. . ................... ......... 13

/ CONTENTS \

STEREO CASSETTE TAPE DECK

T-ASX

"' V V This product is manufactured to

5 comply with the radio inter-
V ference requirements of EEC
Directive "76/889/EEC & 82/
499/EEC".

IMPORTANT NOTICE (For KU and KC models)

The serial number for this equipment is located on the rear panel.
Please write this serial number on your enclosed warranty card and
keep in a secure place. This is for your security.

WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR
MOISTURE.

LINE VOLTAGE SELECTION

(D and D/G models only)

Before your model is shipped from the factory, the switch is set

to the power requirements of the destination; nevertheless, you

should check that it is set properly before plugging the power cord

into the AC outlet.

1. Disconnect the power cord.

2. Provide yourself with a medium size screwdriver.

3. Insert the screwdriver into the groove on the voltage selector
and adjust the voltage value of your area.

Screwdriver

HEM (for Europe excluding U.K.), HB (for U,K.), HP (for
Australia), KU (for U.S.A.) and KC (for Canada) models are
not provided with a LINE VOLTAGE SELECTOR switch.

Using the Accessory Functions ..

Recording and Playback Using
the Audio Timer .. .. 16

Maintenance
Troubleshooting ....... . ............
Cassette Tapes
Specifications

(lb mower-2m
