STEREO CASSETTE DECK

Operating v--_
Instructions C 4- 656MARKH

l

C

-5707

MMDNEEII ........ Ix CFSSGMARKI mmsmn

....=::.-o e o

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will
know how to operate your unit properly. After you have finished
reading the instructions, keep the manual in a safe place for
future reference.

In some countries or regions, the shape of the power plug and
power outlet may sometimes differ from that shown in the
drawings. However, the method of connecting and operating the
unit is the same.

WARNING: To PREVENT FIRE 0R SHOCK
HAZARD. DO NOT EXPOSE THIs APPLIANCE T0
RAIN 0R MOISTURE.

IMPORTANT NOTICE
[For us. and Canadian models]

The serial number for this equipment is located on the rear panel.
Please write this serial number on your enclosed warranty card
and keep it in a safe place. This is for your security.

[For Canadian model]

CAUTION: To PREVENT ELECTRIC SHOCK DO
NOT USE THIs (POLARIZED) PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER
OUTLET UNLEss THE BLADES CAN BE FULLY
INSERTED To PREVENT BLADE EXPOSURE.

ATTENTION: POUR PREVENIR LEs CHocs
ELECTRIOUES NE PAS UTILISER CETTE FICHE
POLARISEE AVEc UN PROLONGATEUR UNE PRISE
DE COURANT ou UNE AUTRE s0RTIE DE
CCURANT, SAUF sI LEs LAMEs PEUVENT ETRE
INSEREES A FOND SANS EN LAISSER AUCUNE
PARTIE A DECOUVERT.

The illustration shows model CT-656 MARKII.

LINE VOLTAGE SELECTOR SWITCH

Only multi-voltage models are provided with this

switch. U.S., Canadian, European. U.K., and

Australian models are not provided with this switch.

Mains voltages in Saudi Arabia are 127V and 220V

only. Never use this model with 110V setting in

Saudi Arabia.

The line voltage selector switch is on the rear panel. Before your

model is shipped from the factory, this switch is set to the power

requirements of the destination. Check that it is set properly

before plugging the power cord into the AC wall socket. If the

voltage is not properly set or if you move to an area where the

voltage requirements differ, adiust the selector switch as

follows.

1. Disconnect the power cord.

2. Use a medium-size screwdriver.

3. Insert the screwdriver into the groove on the voltage selector,
and adjust so that the tip of the arrow points to the voltage
value of your area.

Volts

/

Medium-size
screwdriver

This product complies with the Radio Interference require-
ments of the EC [European Community} Directive 87/308/EEC. "

(I!) PIONEER

The future oi sound and vision.
