Pioneer csa 700 service manual
This is the 10 pages manual for pioneer csa 700 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from pioneer csa 700 service manual (Ocr-read)
Page 1
cs-A700 1. SPECIFICATIONS Enclosure: Speakers: Woof er Mid range Tweeter lnput impedance: Frequency range: Sensitivity: Maximum inputpower: Crossover frequency: Totally enclosed t pe 12"(30cm) cone type 5"(12cm) cone type Multi-cellular horn type 8 ohms 35 to 20,000H2 95dB/W at 1m distance 60w 'e Lows. .. Midranges 500H2 Midranges ..... Highs 5,000H2 (ln case multi-channel amplifiers are used) 2-channel amplifiers: Lows . . Mid-ranges and Highs 3-channel amplifiers: Lows. .. Midranges Midranges ..... Highs External dimensions: Weight: NOTE: 500 to 1,000H2 500 to 1.000H2 4,000 to 6,000H2 660(H) x 380(W) x 320(D)mm 26"(H) x 15"(W) x 12 19132"(Dl 16.9ks (37 lb3 oz) Specifications and the design subject to possible modification without notice due to improvements. 1t0 L|STENIT rw -- -lt --z ........ \=r rlNClll5/A rNoihAL /'K; t;,,";; ^V.r;{\' o i00 7soU2ao |#70 60 6 t00 3so 260 H?o 60 30 a ?5za ro A r5 !'0 5 200 500 FREQU FNC Y n00 2w I N liz -4\4 0' a0\ \.,^"/ 240 500 1000 2000 FREQUENCY I N Hz 200 500 lm FREQUENcY i N Hz sma.
Page 2
b. V. REPLACEMENT OF NETWORK UNIT Remove all of the speakers according to Item 2. Remove all screws from the back board. Now, the board is still held to the back of the cabinet by 4-pinch clips inside of the cabinet, two on the upper side and two on the lower side. Remove the back board by gently rapping on both its upper and lower sides through the opened speaker hole in the baffle. After removal of the back board,disconnect all lines. The network is secured firmly by means of a binding agent as well as tackers. If only a coil or a capacitor has been damaged, it is advisable to renew only the damaged part. Should the network be replaced, insert a minus screw driver or the like, between the back panel and the network and, gradually, remove the network. While attaching the network board to the back board, secure it tightly using a binding agent as well as tackers. If tackers are not available, wood screws wili do. After the network has been exchanged and attached to the back panel, re-connect all wires to their respective terminals again. Insert the panel into the cabinet frame again, and screw it tightly to the cabinet. VI. REPLACEMENT OF INPUT TERMINALS (BLUE AND WHITE) a. Remove the middie range speaker according to Item 2-II Remove screws with a plus screwdriver from the opened speaker hole shown in the photo b. In so doing, care should be taken not to drop the screws. Then, the terminal can be replaced. The leads should be connected to the re- spective terminal side, Blue terminal is for the positive and White one is for the negative terminal, After connection of the terminals, apply a binding agent or the like on the screws to prevent them from loosing. cs-A700 l',iPhoto 3 c. d. 'O Photo 4
