Pioneer clj 75 ld service manual

Page 1

GD PIONEER"

The An of Entertainment

Service

[IMMIIIWOI
O

6
g-#S.
Manualg
R RV1 2 1 5
. CL-J35LD
DEMO
STEREO CLD CASSEI | E DECK RECEIVER
C L - J 5 5 L D
C L - J 7 5 L D
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model 1 The voltage can be convened by the
Type CL-JasLD CL-J55LD CLPJ75LD PM Reqm'emem following method.
KU O - - ACIzov
SD 0 O O AC1 10- 115/120- 127/220- 230/240V With lhe vollage seleclor
SD/HO O O - AC1 10- ] 15/120- 127/220- 230/240V With the voltage selector
SL 0 O O AC1 10- l l5/lZO/220- 230/240V With the voltage selector
S/DF , O - AC1 10- 115/120- 127/22D- 230/240V Wilh the vollage selecor
HE O - O Aczzo - 230v
HE/FR O - O ACZZO - 230v -
HEZl/Dl O - O Aczzo - 230v .-
HB - - O Ac23av _

o For the following : CL-J35LD/SD, SD/HO, SL, HE, HE/FFI and HEZI/Dl; CL-JSSLD/SD, SD/HO,
SL and S/DF; CL-J75LD/SD, SL, HE, HE/FFI, HEZI/DI and HB, refer to pages 163 through 181.

CO NTE NTS
1. SAFETY INFORMATION -------------------------------- 2 34 IC INFORMATION ---------------------------------- 151
2} DISASSEMBLY ............................................ 4 9 FL INFORMATION .................................. 155
3. EXPLODED VIEWS, PACKING 1o. BLOCK DIAGRAMS ------------------------------ 157
AND PARTS LIST ----------------------------------------- e 11. FOR CL-J35LD/SD, SD/HO, SL. HE, HE/FR.
4. SCHEMATIC AND HEZI/DI. CL-J55LD/SD. SD/HO, SL,
PCB CONNECTION DIAGRAMS -------------------- 22 S/DF. CL-J75LD/SD, SL, HE. HE/FR.
5. PCB PARTS LIST ----------------------- ---~121 HEZI/DI AND HE ------------------------------- 163
e. SELF-DIAGNOSTIC FUNCTIONS ----------------- 129 12. PANEL FACILITIES -------------------------------- 132
7_ ADJUSTMENTS ........................................ 131 13' SPECIFICATIONS .................................. 186

PIONEER ELECTRONIC CORPORATION 4-1. Meguro 1-Chome, Meguro-ku, Tokyo 153. Japan

PIONEER ELECTRONICS SERVICE INC. PO. Box 1760, Long Beach. Calilornia 90801 USA

PIONEER ELECTRONICS OF CANADA, INC. 300 Allstate Parkway Markham. Onlario L3FI 0P2 Canada

PIONEER ELECTRONIC [EUROPE] N.V. Haven 1087 Keelberglaan 1. 9120 Melsele. Belgium

PIONEER ELECTRONICS AUSTRALIA PTV. LTD. 178-184 Boundary Road. Blaeside. Vicloria 3195, Austvalia TEL: IDS] 580-9911

© PIONEER ELECTRONIC CORPORATION 1995

T»IFG JANT 1l95 Primed in Japan

Page 2

CL- J35LD, CL- J55LD,
CL- J75LD

1. SAFETY INFORMATION

This service manual is Intended for qualified service technicians; It is not meant for the casual
do-it-yourselfer. Oualifled technicians have the necessary test equipment and tools, and have been
trained to properly and safely repair complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void
the warranty. If you are not qualified to perform the repair of this product properly and safely. you should

not risk trying to do so and refer the repair to a qualified service technician,

WARNING

Lead in aoider used In this product is listed by the California Health and Welfare agency as I known reproductive toxicant which
may cause birth defects or other reproductive harm (California Health It Safety Code, Section 25249.5).

When servicing or handling circuit boards and other components which contain lead in solder. avoid unprotected skin contact with
the solder. Also, when soldering do not inhale any smoke or fumes produced.

NOTICE
(FOR CANADIAN MODEL ONLY)

Fuse symbols JEE- (fast operating fuse) and/or E (slow operating fuse) on PCB indicate that replacement pans

must be of identical designation.

REMARQUE
(POUR MODELE CANADIEN SEULEMENT)

Les symboles de fusible -EB~ (fusible de type rapids) ellou {EB- (fusible de type lent) sur CCI indiquent que les

pieces de remplacement doivent avoir la meme designation.

"(FOR USA MODEL ONLY)

1.SAFETY PRECAUTIONS

The following check should be performed for the
continued protection of the customer and service
technician.

LEAKAGE CURRENT CHECK

Measure leakage current to a known earth ground
lwater pipe. conduit, etc.) by connecting a leakage
current tester such as Simpson Model 2292 or

metal parts of the appliance (input/output terminals,
screwheads, metal overlays, control shaft, etc). Plug
the AC line cord of the appliance directly into a 120V
AC BOHz outlet and turn the AC power switch on. Any
current measured must not exceed 0.5mA.

Ll Reading should

o
Leakage nol be above
current 0-5'"A
tester

DEVICE
under
test

Test all
exposed metal
surfaces

@ Also rest with
plug reversed
lUsing AC adapter
plug as required]

Earth
ground

AC Leakage Test

equivalent between the earth ground and all exposed.

ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A PO-
TENTIAL SHOCK HAZARD AND MUST BE COR-
RECTED BEFORE RETURNING THE APPLIANCE TO
THE CUSTOMER.

2. PRODUCT SAFETY NOTICE

Many electrical and mechanical parts in the appli~
ance have special safety related characteristics. These
are often not evident from visual inspection nor the
protection afforded by them necessarily can be ob-
tained by using replacement components rated for vol-
tage, wattage. etc. Replacement parts which have
these special safety characteristics are identified in
this Service Manual.

Electrical components having such features are

identified by marking with a A on the schematics and
on the parts list in this Service Manual.
The use of a substitute replacement component which
dose not have the same safety characteristics as the
PIONEER recommended replacement one, shown in
the parts list in this Service Manual, may create shock,
fire. or other hazards.

Product Safety is continuously under review and
new instructions are issued from time to time. For
the latest information. always consult the current
PIONEER Service Manual. A subscription to, or ad-
ditional copies of, PIONEER Service Manual may be
obtained at a nominal charge from PIONEER.
