Pioneer cds 9036 zt service manual

This is the 45 pages manual for pioneer cds 9036 zt service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 45
pioneer cds 9036 zt service manual

Extracted text from pioneer cds 9036 zt service manual (Ocr-read)


Page 1

2 CDS-9036ZT 1. SAFETY INFORMATION This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair complex products such as those covered by this manual. Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty. If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so and refer the repair to a qualified service technician. -CD Player Service Precautions 1. For pickup unit(CXX1231) handling, please refer to"Disassembly"(CX-597 Service Manual CRT1829). During replacement, handling precautions shall be taken to prevent an electrostatic discharge(protection by a short pin). 2. During disassembly, be sure to turn the power off since an internal IC might be destroyed when a con- nector is plugged or unplugged.3. Please checking the grating after changing the ser- vice pickup unit(see page 31).

Page 2

3 CDS-9036ZT 7 5 3 2 6 10 9 4 8 1 2. EXPLODED VIEWS AND PARTS LIST 2.1 PACKING NOTE: -Parts marked by "*"are generally unavailable because they are not in our Master Spare Parts List. -Screws adjacent to Ñmark on the product are used for disassembly. -PACKING SECTION PARTS LIST Mark No. Description Part No.Mark No. Description Part No. 1 Screw Assy CEA1854 2 Protector CHP1944 3 Protector CHP1945 * 4 Sheet CHW1645 5 Owners Manual CRD2796 (English,Thai)* 6 Polyethylene Bag E36-609 7 Carton CHA2424 8 Contain Box CHL3594 * 9 Polyethylene Bag CEG-127 10 Screw HMF50P080FMC
