Page 1
@ry@ W ir,tt l kal -- \^:j D!REET-NRIV€ TURNTAMLE The PL-71 ls the top-of-t!'le-l*ne snamua! tunniable. Ets $ervo- csntrolled dlrect-drive systenn and preaisien-crafted S-shaped tonear*n provide aecunate dise trasing aatd reliable perfor- Efianee. TB're results of the direct-drnve system are indleated in the speeifieations, with* wour and $!a;tter of less thcn S"S5% {WRMS} and signa!-to-nsise ratic of 60dF, and emss.tre um* faElinE ficcuracy im turntable rotatEon. A double-eomstruetion solid howl-proof eabinet e onrpleanents these feata*res ar"ld con- trEbutes to stable perfornmaa'*ee. Sthen features incEude *2% speed cor"rtrols with etrcbo tf;rning deviee, anti-skating con*roE, oil-damped eueEng devEee, direet-readsut stylus pressurs scaie, ldghtweight piug-in heedshell, large lnsulators and duet cover with free-stop hirege. SFEEEFIEAT;ONS Srlve $ystem/tUlstsr: Wow and Flnstter: $ignal-to-ftk:lse ffi atie; Tonearnn: ffiEagnemsficsns: WeigEtt: Sireet-drive/Brus[rNess DC servo rs'a*tor &-ess tpram 0.s5% {wR$/l$} More than 60dB Static-balance type S-shaped pipe arilR 1S-29/32(W) x 7-9/32(t"l) x '!6-11/32iP) inehes ?4 Fb. 4 oa.
Page 2
IrL-5tADIRECT.DRIVE TURNTABLE The PL-51A direct-drive turntable features a brushless DC servo motor and solid construction cabinet to provide a very high degree of performance. The high-sensitivity, S-shaped tonearm is distinguished by its accurate tracing capability at light-track pressures. Other features include +2% speed controls with strobo timing device, anti-skating control. oil-damped cueing device, direct-readout stylus pressure scale, large insulators and dust cover with free-stop hinge. SPECIFICATIONSDrive System/Motor: Direct-drive/Brushless DC servo motor Wow and Flutter: Less than 0.05% (WRMS) Signal-to-Noise Ratio: More than 58 dB Tonearm:Dimensions:Weight: Static-balance type S-shaped pipe arm 18-29/32(W) x7-9/32(H) x 16-11/32(D) inches 23lb.2oz. PL- I lEitrI FULL.AUIO TURNTABLE The PL-A4SD is a unique double-motor belt-drive, fully automatic turntable. Auto lead-in, auto-repeat, auto-return and auto-cutoff are accomplished by a separate gear motor. Rotation to the 12-inch aluminum platter is supplied by a 4-pole synchronous motor. Other features include high-sensitivity S-shaped tonearm, anti-skating control, oil-damped cueing device, solid double- construction cabinet, dust cover and free-stop hinge. SPECIFICATIONSDrive System/Motors: Wow and Flutter: Signal-to-Noise Ratio: Tonearm:Dimensions:Weight: Belt-drive/4-pole synchronous motor and Precision gear motor Less than 0.1% (WRMS) More than 47dB Static-balance type S-shaped pipe arm 18-29/32(W) x 6-25l32(H) x 16-11/32(D) inches 22lb.8oz. IrL-l?;trl BELT.DRIVE TURNTABLE The fine 4-pole synchronous motor and 12-inch aluminum alloy die-cast platter are linked in a stable belt-drive mechanism. The S-shaped tonearm employs a super-hard alloy at the pivot point so that high sensitivity and stability are beautifully blended. Other features include anti-skating control, oil-damped cueing device and dust cover. SPECIFICATIONSDriveSystem/Motor: Belt-drive/4-polesynchronous motor Wow and Flutter: Less than 0.1% (WRMS) Signal-to-Noise Ratio: More than 47dB Tonearm:Dimensions:Weight: Static-balance type S-shaped pipe arm 16-15/16(W) x 6-15/32(H) x14-1/4(D) inches 16 lb. 5 oz. F'L. IO BELT.DRIVE TURNTABLE A budgetpriced stereo turntable, the PL-10 employs Pioneer's proven belt-drive system with a 4-pole synchronous motor and 12-inch aluminum alloy dynamically-balanced platter. The lightweight S-shaped tonearm with anti-skating control, and other features including oil-damped cueing device, direct-readout stylus pressure scale, walnut-grain cabinet with dust cover are included. SPECIFICATIONSDriveSystem/Motor: Belt-drive/4-polesynchronous motor Wow and Flutter: Less than 0.1% (WRMS) Signal-to-Noise Ratio: More than 47dB Tonearm:Dimensions:Weight: Static-balance type S-shaped pipe arm 16-15/16(W) x 6-17/32(H) x 13-11/32(D) inches 141b. 12o2.
