Extracted text from pioneer catalogs 1980 81 cat us (Ocr-read)
Page 1
STffireffi# ffiMGNIVERS ffiwffiffiffiffi FM/AM STEREO RECETVER ("NON-SWITCHING AMprM', & DTGTTAL/QUARTZ-SERVO LOCKED TUN I NG) Gontinuous Fower output is 120 watts* per channel, min. at 8 ohms from 20 heflz to 20,000 hertz with no more than 0.005% total harmonic distortion. FM Usable Sensitivity: Mono; 9.8dBf (1.7pV) FM Capture Ratio: 1.OdB FM Alternate ChannelSelectivity: SOdB FM S/N Ratio: 83dB (mono, at 65dBf), 78dB (stereo, at 80dBf) FM Stereo Separation: 50dB (1kHz), 35dB (30-15,000H2) FM Spurious Response Ratio: 100d8 AM Suppression Ratio: 60dB Dimensions: Zo1%a" (W)X61%0"(H)x1 vatru" (D) Weight: 441b. 1oz. 'Walnut grained vinyl top and side panels are used in the construction of this cabinet. FM/AM STEREO RECETVER ("NON-SW|TCH|NG AMprM'& DTGTTAL/QUARTZ-SERVO LOCKED TU NtNG) Gontinuous power output is 60 watts* per channel, min. at 8 ohms from 2O hertz to 20,000 hertz with no more than 0.005% total harmonic distortion. FM Usable Sensitivity: Mono; 10 gdBf (1.8pV) FM Capture Ratio: 1.0dB FM Alternate Channel Selectivity: 75dB FM S/N Ratio: 83dB (mono, at 65dBf), 78dB (stereo, at BOdBf) FM Stereo Separation: 45dB (1kHz), gSdB (90-1S,OOOHz) FM Spurious Response Ratio:65d8 AM Suppression Ratio: SSdB Dimensions: 191%0"(W)X 6%a" (H) x 1 7%a" (Dl Weight: gSlb. 11 oz. 'Walnut grained vinyl top and side panels are used in the construction ol this cabinet. * Prices indicated are manulacturer's suggested retailprices as of Oct. 1, 1980. FM/AM STEREO RECETVER (DTGTTAL/QUARTZ-SERVO LOCKED TUNTNG) Continuous power output is 45 watts* per channel, min. at 8 ohms from 20 herlz to 20,000 hertz with no more than 0.02% total harmonic distortion. FM Usable Sensitivity: Mono; 10.3dBf (1.8rrv) FM Capture Ratio: 1.OdB FM Alternate ChannelSelectivity: 75dB FM S/N Ratio: SOdB (mono, at 65dBf), 75dB (stereo, at 85dBf) FM Stereo Separation: 45dB (1kHz), 35dB (30-15,000H2) FM Spurious Response Ratio:65d8 AM Suppression Ratio: 55dB Dimensions: 18%"(W)X5%"(H)x 145Aa" (D) Weight: 25 lb. 9 oz. rWalnut qrained vinyl top and side panels are used in the construction of this cabinet. FM/AM STEREO RECEIVER Gontinuous power output is 30 watts* per channel, min. at 8 ohms from 20 hertz to 20,000 hertz with no more than 0.05% total harmonic distortion. FM Usable Sensitivity: Mono; 11.2dBf (2.0pV) FM Capture Ratio: 1.OdB FM Alternate Channelselectivity: 6OdB FM S/N Ratio: 78dB (mono, at 65dBf), 72dB (stereo, at 85dBf) FM Stereo Separation: 40dB (1kHz), SSdB (30-1S,000H2) FM Spurious Response Ratio:65d8 AM Suppression Ratio: SSdB Dimension s: 17 1 %a" (W)X 5 %e"( H ) x 1 21A6" (D) Weight: 1 8 I b. 1 oz. *Walnul-like metal top and walnut grained vinyl side panels are used in the construction ol this cabinet. "Measured pursuant to the Federal Trade Commission's Trade Regulation Rule on Power Output Claims for Amplifiers. ffiwffiffiffiffi
Page 2
FM/AM STEREO RECEIVER Gontinuous Power Output is 20 watts* per channel, min. at 8 ohms from 20 hertz to 20,000 hertz with no more than 0.05% total harmonic distortion. FM Usable Sensitivity: Mono; 11.2dBf (2.0pV) FM Gapture Ratio: 1.0d8 FM Alternate Channel Selectivity: 75dB FM S/N Ratio: 78dB (mono, at 65dBf), 72dB (stereo, at 85dBf) FM Stereo Separation: 40dB (1kHz), 35dB (30-15,000H2) FM Spurious Response Ratio:65d8 AM Suppression Ratio: 55dB Dimensions: 171%a" (w)XS%0"(H)x12%a" (D) weight: 16 lb. 12 oz. 'Walnut-like metal top and walnut grained vinyl side panels are used in the conslruction ol this cabinet. FM/AM STEREO RECEIVER Gontinuous Power Output is 15 watts* per channel, min. at 8 ohms from 20 hertz to 20,000 hertz with no more than 0.08% total harmonic distortion. FM Usable Sensitivity: Mono; 12.1 dBf (2.ZpY FM Capture Ratio:2.5d8 FM Alternate Channet Selectivity:6OdB FM S/N Ratio: 75dB (mono), 70dB (stereo), (at 6SdBf) FM Stereo Separation: 45dB (1kHz), 30dB (90-1S,OOOHz) FM Spurious Response Ratio:65d8 AM Suppression Ratio: sodB Dimensions: 1T%,'(w )X5%0,'(H)X111/2,,(D) weight: 12lb. 2 oz. 'Walnut-like metal top and walnut grained vinyl side panels are used in ihe construction ol this cabrnet TUNERS sA-9AOO *o*$*'tc*Nc AMP STEREO INTEGRATED AMPLIFIER ("NON-SWITCH I NG AMPTM") Gontinuous power output is 100 watts* per channel, min. at 8 ohms from 10 hertz to 20,000 hertz with no more than 0.005% total harmonic distortion, or 100 watts* per channel at 4 ohms from 10 hertz to 20,000 hertz with no more than 0.005% total harmonic distor- tion.Intermodulation Distortion: O.OO20A (continuous rated power output) Frequency Response: PHONO (RIAA Equatization); 20-20,000H2 +0.2d8, POWER AMP.; 5-200,000H2 *0d8, -2.0d8 Damping Factor:55 (20-20,000H2, 8 ohms) Dimen- sions: 17tt/'u" (W)X6%"(H)X163/4"(Dl Weight: 40Ib. goz. "Walnut grained vinyl top and side panels are used in the construction of this cabinet. StuBEtctct TCHING AMP STEREO INTEGRATED AMPLIFI ER ("NON-SWITCH I NG AMPTM") Gontinuous power output is 80 watts* per channel, min. at 8 ohms lrom 10 hertz to 20,000 hertz with no more than 0.005% total harmonic distortion, or 80 watts* per channel at 4 ohms from 10 hertz to 20,000 hertz with no more than 0.005% total harmonic distortion. lntermodulation Distortion: O.OO2oA (continuous rated power output) Frequency Response: PHONO (RIAA Equalization); 2O-2O,OOOHz r0.2dB, POWER AMP.; 5-200,000H2 +0d8, -2.0d8 Damping Factor:55 {20-20,000H2, I ohms) Dimen- sions: 17 t ttr utt (W )x6%" ( H )x 1 631" (Dl Weight: 34 I b. 6 oz. "Walnut grained vinyl top and side panels are used in the construction ot this cabinet. STEREO AMPLIFIERS &
