Pioneer A Stereo Components 1972
This is the 12 pages manual for Pioneer A Stereo Components 1972.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Pioneer A Stereo Components 1972 (Ocr-read)
Page 2
RECEIVERS, TUNERS 82 AMPLIFIERS
SX-BOOO
240W AM/FM STEREO RECEIVER WITH BUILT-IN REVER~
BERATION
Continuous Power Output. 50 watts + 50 watts lat 8 ohms, both
channels drivenl/Power Bandwidth (IHF, both channels driveni:
10-35,000Hz (at 8 ohms, harmonic distortion less than 0.5% )/
FM Sensitivity (IHF): 1.6uV
. .t v '91.», 4, g 3'», p Q
195W SENSITIVE AM/FM STEREO RECEIVER WITH SUPERB
VERSATILITY
Continuous Power Output: 40watts + 40 watts (at 8 ohms, both
channels drivenl/Power Bandwidth (IHF, both channels driven):
1077O,000Hz (at 8 ohms. harmonic distortion less than 1%)/
FM Sensitivity (IHF): 2:0uV
Epsinaseam
340W AUTOMATIC TUNING AM/FM STEREO RECEIVER
Continuous Power Output: 72 watts + 72 watts (at 8 ohms, both
channels drivenl/Power Bandwidth (IHF, both channels driven):
8-40.000Hz (at 8 ohms, harmonic distortion less than 0.5% )/
FM Sensitivity (IHF): 1.6}AV
110W AM/FM STEREO RECEIVER WITH SUPERB VERSA-
TILITY
Continuous Power Output: 27 watts + 27 watts (at 8 ohms. both
channels driveni/Power Bandwidth (IHF, both channels driven):
10-70.000Hz (at 8 ohms. harmonic distortion less than 1% )/FM
Sensitivity (IHF): 2.0uV
SEX-BE.
240W AM/FM STEREO RECEIVER WITH ADVANCED CIR-
CUIT DESIGN
Continuous Power Output: 60 watts + 60 watts (at 8 ohms.
both channels driveni/Power Bandwidth (IHF. both channels
driven): 10-60,000Hz (at 8 ohms, harmonic distortion less than
0.5% )/FM Sensitivity (IHF): 1.7uV.
72W MEDIUM-POWERED AM/FM STEREO RECEIVER
Continuous Power Output:17 watts + 17 watts (at 8 ohms, both
channels drivenl/Power Bandwidth (IHF, both channels driven)
10-45,000Hz (at 8 ohms, harmonic distortion less than 1%)/
Sensitivity (IHF): 2.2;1V
