(1) Traffic event Stopped traffic Stop and go traffic Closed/blocked roads Other event (e.g., accident)(2) Traffic flow The following items represent the traffic flow for the road. 5-15 mph (8-24 km/h) 20-40 mph (32-64 km/h) 45 mph or faster (72 km/h or faster) The icon indicates that the average speed of the road is over 45 mph (72 km/h). Operation of XM Satellite Radio You can use the navigation system to control a XM satellite digital tuner. GEX-P10XMT (sold separately) is required, together with an active subscription. (1)Shows detailed information of current broadcast. (2)Use to change the channel select mode. (3)Each touch allows you to change the left screen in the following order: Detail information display – Ch Name List – Song Title List – Artist Name List Operation of your Apple iPod ® You can control your iPod with Dock connector via the touch screen when it is connected to this navigation system via Pioneer iPod adapter (sold separately). Changing the AV source 1 Touch the source icon. 2 Touch the desired AV source. (1)You can switch the AV source for rear display in the following order. MIRROR(Same as front) – DVD(DVD drive) – AV (AV input) Operation of Music Library First, you need to play a CD for recording into the built-in hard disk drive. (The recording is carried out by 4 times speed in parallel with playing that CD.) After the recording, you can find and select the song easily from a playlist. (1)Search a song by album name, artist name, genre, customized playlist. (2)Touch and hold to memorize that song as My Mix playlist. (3)Information of current song (4)Group playing now. Setting the voice guidance volume Basic operation on the map screen Scrolling the map Touch where you would like to scroll to on the map screen. (1)Next street (2)Distance to the next guidance point (3)Distance to your destination (4)Estimated time of arrival (in default) Mute the navigation voice Touch . Short-cut MenuTouch . Zoom in or zoom outTouch or . Press or touch in the following order. button ➔Settingstab ➔Volume Traffic information on the map Traffic conditions can be overlaid on the map. GEX-P10XMT XM Digital Satellite Data & Audio Receiver (sold sepa- rately) is required, together with an active subscription for the XM NavTraffic service. (1)(2) (2) (1) (3) (4) (2) (3) (1) (1) (2)(1) (4)(3) Touch to display the search cate- gories.
