Pioneer AVIC N3 Owners Manual
This is the 61 pages manual for Pioneer AVIC N3 Owners Manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from Pioneer AVIC N3 Owners Manual (Ocr-read)
Page 1
1 IMPORTANT INFORMATION ABOUT YOUR NEW NAVIGATION SYSTEM AND THIS MANUAL - The navigation features of this product (and rear view camera option if\ pur-chased) is intended solely as an aid to you in the operation of your ve\ hicle. It is not a substitute for your attentiveness, judgment and care when driving.\ - Never use this navigation system to route to hospitals, police stations,\ or similar facilities in an emergency, Please call 911. - Do not operate this navigation system (or the rear view camera option i\ f pur- chased) if doing so in any way will divert your attention from the safe\ operation of your vehicle. Traffic restrictions and advisories currently in force \ should always take precedence over guidance given by this product. Always obey \ current traffic restrictions, even if this product provides contrary advice. - Certain government laws may restrict the placement and use of navigation\ sys- tems in your vehicle. Please comply with all applicable laws and regulat\ ions in the installation and operation of your navigation system. - This manual explains how to install this navigation system in your vehic\ le. Operation of this navigation system is explained in the separate Operati\ on Manual or Hardware Manual for the navigation system. - Do not install the display unit or Hide-away unit where it may (i) obs\ truct the dri- vers vision, (ii) impair the performance of any of the vehicle\ s operating systems of safety features, including airbags, hazard lamp buttons or (iii) im\ pair the dri- vers ability to safely operate the vehicle. In some cases, it may no\ t be possible to install this product because of the vehicle type or the shape of the veh\ icle interior.
Page 2
English IMPORTANT INFORMATION .................... 1 ABOUT YOUR NEW NAVIGATIONSYSTEM AND THIS MANUAL .............. 1 IMPORTANT SAFEGUARDS .................... 3 PLEASE READ ALL OF THESE INSTRUCTIONS REGARDING YOUR NAVIGATION SYSTEM AND RETAIN THEM FOR FUTURE REFERENCE .................... 3 Connecting the System ............................ 4 -Before installing this product-To prevent damage-Parts supplied Connecting the system ...................................... 7 Connecting the power cord (1) .......................... 9 Connecting the power cord (2) ........................ 11 When connecting to separately sold power amp .......................................................... 13 When connecting a Rear view camera ............ 15 When connecting the external video component and the display .......................................... 16 -When using a display connected to rear video output Installation ................................................ 17 To guard against electromagnetic interference .............................................. 18 Before installing .............................................. 18 Installing the display unit and Hide-away unit ........................................ 19 -Installation notes-Parts supplied-Installing the Hide-away unit-DIN Front/Rear-mount-DIN Front-mount-DIN Rear-mount-Fixing the front panel Installing the GPS antenna .............................. 26 -Installation notes-Parts supplied-When installing the antenna inside the vehi- cle (on the rear shelf) -When installing the antenna outside the vehi- cle (on the body) After Installing this Product.................... 29 2 Contents
