Philips sw 3500 service manual
This is the 17 pages manual for philips sw 3500 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips sw 3500 service manual (Ocr-read)
Page 1
1-2 LOCATION OF PC BOARDS AMPLIFIER BOARD INPUT BOARD POWER BOARD LED BOARD SPECIFICATIONS SUBWOOFER Subwoofer (not magnetically shielded design).......................................................................................................6.5" Output Power.........................................................................................................................................75W (4Ω,DIN) THD (Total Harmonic Distortion) ...................................................................................10% at 80 Hz (output power) Reproduction Frequency Response.......................................................................................................30 Hz-180 Hz Phase Switch....................................................................................................................................................0 0,180 0 Input Sensitivity (Subwoofer In).................................................................................................................200 mVrms AC Power (for SW3500/37S) ..................................................................................................................120V / 60 Hz AC Power (for SW3000/06S; SW3500/06S) .................................................................................110 ~ 127V / 60 Hz AC Power (for SW3000/00S) ........................................................................................................ 220 ~ 240V / 50Hz AC Power (for SW3000/00S;SW3500/02S) .......................................................................... 220 ~ 240V / 50 / 60 Hz power Consumption...........................................................................................................53 W (at 1/8 Rated Power) Dimensions (w x h x d)...................................................................................................130 mm x 337 mm x 375 mm Weight...................................................................................................................................................................7 Kg
