Philips rfx 6000 brochure

Page 1

RFX6000/01 RF extender Product highlights IR extension module An infrared extension module allows you to control traditional infrared equipment over a radio frequency network. Radio frequency A radio technology that allows you to control components not in direct line-of-sight, such as through walls or other obstacles. There are two types of RF used in remote controls: RF to component, and RF to infrared. Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners. © 2005 Koninklijke Philips Electronics N.V. All Rights reserved. www.philips.com Date of issue 2005-05-27 Version: 1.0 12 NC: 3104 207 12151 UPC: 0 37849 91503 5 Technical specifications Connectivity -IR emitter connectors: 4 -Power: 120 V 60 Hz power adapter Convenience- Error indication Accessories-AC/DC Adaptor: 12V DC 400mA -Dual IR emitter wires: 4 -Printed User Guide Dimensions-Master carton quantity: 1 -Master carton weight: 0.84 kg -Product dimension (WxDxH) inch: 4.5" x 3.2" x 1.2"-Product weight in lbs: 0.132 -Temperature Range (Operation): 32 - 122 degree F Power-Mains power: 120V (+/-10/-15%)/60Hz Infrared Capabilities-Transmitting LEDs: 5 -IR emitter connectors: 4 RF Capabilities-Adresses (ID's): 16 -Channels: 4 -Communication: 1-way -Frequency (MHz): 418
