Philips mcs 240 service manual
This is the 10 pages manual for philips mcs 240 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips mcs 240 service manual (Ocr-read)
Page 1
SERVICE PARTSLIST 9940 000 03619 HANDLE AZ1022 9940 000 03621 HANDLE HINGE (L) AZ1022 9940 000 03622 HANDLE HINGE (R) AZ1022 9940 000 03623 ROD ANTENNA AZ1022 9940 000 03624 BATTERY DOOR AZ1022 9940 000 03625 CD DOOR MCS240 9940 000 03626 CD DOOR SPRING AZ1022 9940 000 03627 CD DECK DA11B3VF (SANYO) 9965 000 16882 CUSHION 658PG (BLACK) 9965 000 16883 CUSHION 658PH (GREY) 9940 000 03628 SPEAKER 3 1/2 8 OHM 2W 9940 000 03629 BAND SWITCH : SST-63D01-G9-NS 9965 000 13705 TACT SWITCH : DT4113C 9940 000 03631 VOL CONTROL R1411GUXVIB503FP 9965 000 17021 TRANSFORMER T41-0586 9940 000 00553 VDE POWER CORD SET 2
Page 2
3 3 WIRING DIAGRAM
