Page 1
1-2 VERSION VARIATIONS Type /Versions: Board in used:MCM205 Service policy MAIN BOARD MCU BOARD USB JACK BOARD * TIPS : C -- Component Lever Repair. M -- Module Lever Repair-- Used C /12 /05 /55 8 9 / 1 6 / 8 5 / DISPLAY & KEY BOARD C C TUNER BOARD M x HEADPHONE BOARD C /37 C/M DISPLAY & KEY BOARD HEADPHONE BOARD MCU BOARDTUNER BOARD USB BOARD MAIN BOARD PCBS LOCATION
Page 2
Speakers Speaker Impedance 4ohm General information-Specs Switching mode power supplyModel: GFP181T- 1512-1 o r GFP181DA-1512-1, Input: AC100- 24 0V~, 50/60 Hz, 0.35A Output: DC15V, 1.2A Operation Power Consumption 26 W Standby Power Consumption <4 W Eco Standby Power Consumption <1 W Dimensions - Main Unit ( W x H x D) - Speaker Box ( W x H x D) 152 x232 x 222mm 146 x 232 x 140mm Weight - With Packing - Main Unit - Speaker Box 5.20 kg 1.64 kg 2.20 kg Supported MP3 disc formats ISO9660, Joliet - Maximum title number: 512 (depending - on file name length) Maximum album number: 255 - Suppor ted sampling frequencies: 32 kHz, - 44.1kHz, 48 kHz Suppor ted Bit-rates: 32~256 (kbps), - variable bit rates Speci fications Amplifier Rated Output Power 2X5W RMS Frequency Response 60 - 16kHz, ±3dB Signal to Noise Ratio >62dB Disc Laser Type Semiconductor Disc Diameter 12cm/8cm Suppor t Disc CD-DA, CD-R , CD-RW, MP3-CD, WMA-CD Audio DAC 24Bits / 44.1kHz Total Harmonic Distor tion <1% Frequency Response 60Hz -16kHz S/N Ratio >62dBA Tuner Tuning Range FM: 87.5 - 108MHz; MW: 531 - 1602kHz Tuning grid 50 kHz (FM); 9 kHz (MW) Total Harmonic Distor tion <3% Signal to Noise Ratio >50 dB 1-3
