Philips mcm 148 service manual
This is the 26 pages manual for philips mcm 148 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips mcm 148 service manual (Ocr-read)
Page 1
PCBS LOCATION FRONT BOARDMAIN BOARD 1-2
Page 2
1-3 AMPLIFIER Output power ........................................... 2 x 2W RMS Signal-to-noise ratio ..........................1 60 dBA (IEC) Frequency response ....................... 125 – 16000 Hz Impedance loudspeakers ........................................... 8 " CD PLAYER Frequency range ............................... 125 – 16000 Hz Signal-to-noise ratio ............................................ 65 dBA TUNER FM wave range ................................... 87.5 – 108 MHz MW wave range ................................ 530 – 1700 kHz Sensitivity – FM 26 dB sensitivity .......................................... 20 µV – MW 26 dB sensitivity ................................... 5 mV/m Total harmonic distor tion ..................................... 0 5% SPEAKERS Bass reflex system Dimensions (w x h x d) . 134 x 230 x 152 (mm) GENERAL INFORMATION AC Power ............................ 110 – 127 / 220 – 240 V ....................................................... 50/60 Hz, switchable Dimensions (w x h x d) .. 148 x 233 x 216 (mm) Weight (with/without speaker s) .................................. ......................................................... approx. 3.65 / 1.53 kg Power consumption Active ........................................................................\ .. 15 W Standby .................................................................... < 4 W Specifications and external appearance are subject to change without notice. SPECIFICATIONS
