Philips mcd 149 service manual

This is the 35 pages manual for philips mcd 149 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 35
philips mcd 149 service manual

Extracted text from philips mcd 149 service manual (Ocr-read)

Page 2

1-1

LOCATION OF PCBS

VERSION VARIATIONS:
T /Versions: MCD149

Board in used: Service policy

DISPLAY BOARD
SCART BOARD
USB & KEY BOARD
TUNER BOARD
POWER BOARD
MPEG BOARD

Type Nersions: MCD149

Features eature diffrence
RDS
VOLTAGE SELECTOR
ECO STANDBY - DARK

* TIPS : C -- Component Level Repair.
M -- Module Level Repair
1 -- Used
