Philips mcb 279 service manual
This is the 39 pages manual for philips mcb 279 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips mcb 279 service manual (Ocr-read)
Page 1
/12 /58 n i R D C / n i x u A Line Out Video Out Subwoofer Out Digital Out Karaoke Features Voltage Selector ECO Power Standby (LCD Display Off) USB Direct Type /Versions: MCB279 \ Features in used: /05 VERSION VARIATIONS Type /Versions: Board in used: MCB279 Service policy MAIN BOARD CD BOARD POWER AMP BOARD HEADPHONE BOARD * TIPS : C -- Component Lever Repair. M -- Module Lever Repair-- Used C /12 /05 8 5 59 // 1 6 / 8 5 / Feature diffrence KEY BOARD C C C DAB MODULE M x x x 1 - 2 PCBS LOCATION MOTOR BOARD CC MCU BOARD C x CD BOARD HEADPHONE BOARD KEY BOARDMOTOR BOARD POWER AMP BOARD MCU BOARDMAIN BOARD
Page 2
1 - 3 AMPLIFIER Output power ................................................ 30 W RMS Signal-to-noise ratio ....................................... t 65 dBA Frequency response ............. 100 – 18kHz, ± 3 dB Input sensitivity AUX ....................... 0.5 V (max. 1 V) Impedance loudspeakers ..................................... t6 : Impedance headphones .................... 32 : -1000 : .................................................................................... <15 mW CD PLAYER Frequency range ...................................... 100 – 18 kHz Signal-to-noise ratio ............................................ 65 dBA TUNER FM wave range ................................... 87.5 – 108 MHz MW wave range ................................ 531 – 1602 kHz Number of presets ........................................................ 40 Antenna FM .................................................................... 75 : wireSPEAKERS Bass reflex system Dimensions (w x h x d) .. 158 x 250x 185 (mm) GENERAL INFORMATION AC Power .........................110 – 240 V, 50 Hz/60 Hz Dimensions (w x h x d, with/without the stand) ............... 211 x 250 x 160/211 x 250 x 126 (mm) Weight(with/without speakers) ......... 3.7 / 1.33 kg Standby power consumption ............................ <2 W Eco power standby ............................................... <1 W Specifications and external appearance are subject to change without notice. USB ......................................................................... V2.0/ V1.1 ......................................... suppor t MP3 and WMA files Number of albums/ folders ............. maximum 999 Number of tracks/titles ...................... maximum 999 USB PLAYER SPECIFICATIONS
