Extracted text from philips hts 3580 service manual (Ocr-read)
Page 1
1 - 2 LOCATION OF PCB BOARDS VERSION VARIATION: Type/Versions Features Output Power - 1000W Voltage (220-240V) Main Board VFD+VOL+USB+MP3 Board BD Board Type/Versions Board in used C C Bd /12 SERVICE SCNARIO MATRIX: /12 x x *C = Component Level RepairPower Board C Touch Board C BD PCB MAIN PCB TOUCH PCB VFD PCB Vol+USB+MP3 PCBBPOWER PCB *Bd = Board Level Replacement /93 x x HTS3580 C C Bd /93 C C HTS3580 AUX/MP3 Voltage (220-230V) /98 x x x x xx Voltage (110-127V/220-240V) /51 x x x C C Bd /98 CC C Bd /51 C CC
Page 2
1 - 3 SPECIFICATIONS (RED FOR /93;GREEN FOR /98) Playback media BD-Video, DVD-Video, DVD+R/+RW,DVD-R/-RW, DVD+R/- R DL, CD-R/CDRW,Audio CD, Video CD/SVCD, PictureCD, MP3-CD, WMA-CD, DivX (Ultra)-CD, USB fl ash drive. File Format Audio ........................................................................ mp3, .wma Video ...................................................... .avi, .divx, .mkv, .wmv Picture .................................................................. .jpg, .gif, .png Amplifier Total output power .............................. 1000 W RMS (30%THD) Frequency response .................................. 20 Hz-20 kHz /±3dB Signal-to-noise ratio... ................. > 65 dB (CCIR) /(A-weighted) Input sensitivity: AUX .............................................................................. 500 mV MP3 LINK ...................................................................... 250 mV Video Signal system ........................................................ PAL / NTSC HDMI output ............. 480i/576i, 480p/576p,720p, 1080i, 1080p Audio Sampling frequency: MP3 .................................................. 32 kHz, 44.1 kHz, 48 kHz WMA ............................................................... 44.1 kHz, 48 kHz Constant bit rate: MP3 ........................................................... 112 kbps - 320 kbps WMA ............................................................ 48 kbps - 192 kbps Radio Tuning range .................................. FM 87.5-108 MHz (50 kHz) Signal-to-noise ratio .................................................... FM 55 dB Frequency response ....................... FM 180 Hz-12.5 kHz/ ±3dB USB Compatibility ...............................................Hi-Speed USB (2.0) Class support ......................... UMS (USB Mass Storage Class) File system ............................................. FAT16, FAT32, NTFS Maximum memory support .......................................... < 160GB Main Unit Power supply ........................................... 220-240V; ~50-60 Hz Power supply ........................................... 220-230V; ~50-60 Hz Power supply ...........................110-127V/220-240V; ~50-60 Hz Power consumption ......................................................... 100 W Standby power consumption ........................................ ≤ 0.9 W Dimensions (WxHxD) ................................ 360 x 58 x 351(mm) Weight ............................................................................3.22 kg Speakers Speaker impedance ............ 4 ohm (center), 4ohm (Front/Rear) Speaker drivers .................................................1 x 3 full range Frequency response ...........................................150 Hz-20 kHz Dimensions (WxHxD): Center ......................................................... 161 x 92 x 95 (mm) Speaker ...................................................... 95 x 161 x 87 (mm) Tall speaker ......................................... 254 x 1001 x 254 (mm) Weight: Center ............................................................................ 0.77 kg Speaker ................................................................. 0.56 kg/each Tall speaker ........................................................... 3.38 kg/each Cable length: Center .................................................................................. 3 m Front .................................................................................... 4 m Rear ................................................................................... 10 m Subwoofer Impedance ....................................................................... 4 ohm Speaker drivers ....................................... 165 mm (6.5) woofer Frequency response ............................................ 40 Hz-150 Hz Dimensions (WxHxD) .............................. 123 x 369 x 309(mm) Weight ............................................................................3.81 kg Cable length ........................................................................ 4 m Laser specification Laser Type (Diode) ...................................... InGaN/AIGaN (BD) ................................................... InGaAIP (DVD), A IGaAs (CD) Wave length .............................................. 405 +5nm/-5nm (BD) ............................................................ 650+13nm/-10nm (DVD) ...............................................................790 +15nm/-15nm(CD) Output power (Max. ratings) ......... 20mW(BD), 7mW (DVD/CD) Specifi cations subject to change without prior notice.
