Philips fwp 880 service manual

This is the 108 pages manual for philips fwp 880 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 108
philips fwp 880 service manual

Extracted text from philips fwp 880 service manual (Ocr-read)

Page 1

1-2 LOCATION OF PRINTED CIRCUIT BOARDS /21 /37/37 Aux/CDR In x xx Line Out x xx Surround Out x Subwoofer Out x xx Digital Out x xx Matrix Surround CD Text Dolby B RDS News Dolby Pro Logic (DPL) x Incredible Surround Karaoke Features x V oltage Selector x ECO Power Standby (Clock Display Off) x x x T uner board - ECO5 Sys x xx T uner board - Tuner 95 Center/Surround Channel x Note: 3CDC-LC-MB Module is mechanically the same as 3CDC-LC Module except the \ schematics, layouts & electrical parts list related to the CDC Board.The CDC Board (recognized by 12NC :\ 3103 303 34522 printed on the Board) is introduced as an alternative to supplement for the shortage of Servo \ IC TDA7073A. VERSION VARIATIONS: T ype /Versions: FW-C870 FW-P880 Features & Board in used: ETF7 BOARD POWER SUPPLY BOARD C/S AMP. BOARD MAINS BOARD L/R AMP. BOARD TUNER BOARD HEADPHONE BOARD AF8 BOARD CD BOARD CD KEY BOARD DPL BOARD FRONT BOARD KARAOKE BOARD CONTROL BOARD

Page 2

1-3 SPECIFICA TIONS GENERAL: Mains voltage : 1 10-127V/220-240V Switchable for /21/21M 120V for /37 220V for /33 220-230V for /22/34 230-240V for /30 Mains frequency : 50/60Hz Power consumption : < 2W at ECO Power Standby :< 20W at Standby : 180W at Active Clock accuracy : < 4 seconds per day Dimension centre unit : 265 x 310 x 390mm TUNER: FM T uning range : 87.5-108MHz 65.81-74MHz for /34 1) Grid : 50kHz (& 30kHz for /34) 100kHz for /37 IF frequency : 10.7MHz ± 25kHz Aerial input : 75Ω coaxial 300 Ω click fit for /37 Sensitivity at 26dB S/N : < 7µV Selectivity at 600kHz bandwidth : > 25dB Image rejection : > 25dB [> 75dB] Distortion at RF=1mV, dev. 75kHz : < 3% -3dB Limiting point : < 8µV Crosstalk at RF=1mV, dev. 40kHz : > 18dB MW T uning range : 531-1602kHz 530-1700kHz for /21/21M/37 Grid : 9kHz 10kHz for /21/21M/37 IF frequency : 450kHz ± 1kHz Aerial input : Frame aerial Sensitivity at 26dB S/N : < 4.0mV/M Selectivity at 18kHz bandwidth : > 18dB IF rejection : > 45dB Image rejection : > 28dB Distortion at RF=50mV, m=80% : < 5% LW T uning range : 153-279kHz Grid : 3kHz IF frequency : 450kHz ± 1kHz Aerial input : Frame aerial Sensitivity at 26dB S/N : [< 7.0mV/M] Selectivity at 18kHz bandwidth : [> 24dB] IF rejection : [> 26dB] Image rejection : [> 35dB] Distortion at RF=50mV, m=80% : [< 5%] AMPLIFIER: Output power (6 Ω, 1kHz, 10% THD) L & R : 2 x 150W RMS /FW-C870/21 Output power (6 Ω, 60Hz-12.5kHz, 10% THD) L & R : 2 x 120W FTC /FW-C870/37 L & R : 2 x 115W FTC /FW-P880/37 Surround : 2 x 25W /FW-P880/37 Center : 40W /FW-P880/37 Frequency response within -3dB : 60Hz-16kHz Digital Sound Control (DSC) : Optimal, Classic, Techno, Jazz, Rock, Vocal V irtual Environment Control (VEC) : Hall, Disco, Concert, Club, Cinema, Arcade WOOX : 1, 2, 3 Dolby Pro Logic (DPL) : Dolby Surround Dolby Center Phantom Dolby 3 Stereo Normal Stereo Input sensitivity Aux in : 500mV ± 2dB, 1kHz CDR in : 800mV ± 2dB, 1kHz Microphone : 4mV ± 2dB Output sensitivity Line out (Left/Right) : 500mV ± 2dB at 22 k Ω Subwoofer out (100Hz) : 1.3V ± 2dB at 22 k Ω at maximum volume Surround out (1kHz) : 500mV ± 2dB at 22 k Ω Digital out : IEC 958, 44.1kHz Headphone output at 32 Ω:18mW ± 1dB CASSETTE RECORDER: Number of track : 2 x 2 stereo T ape speed : 4.76 cm/sec ± 2% W ow and flutter : < 0.4% (DIN) Fast-wind/Rewind time C60 : 130 sec Bias system : 75kHz ± 10kHz Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz Signal to noise ratio (unweighted): > 44dB COMPACT DISC: Measurement done at Set level at 6 Ω speaker loads. Frequency response : < ±3dB for 63Hz-14kHz Signal to Noise ratio (Unweighted) : 60dBA Signal to Noise ratio (A-weighted) : 67dBA THD (30Hz-16kHz) : 1.5% Channel difference (250Hz-10kHz) : < ± 2dB Channel separation (20Hz-20kHz) : 30dB (1kHz) : 40dB [....] Values indicated are for "Tuner 95 Board" only. 1) Default setting is OFF, to switch on please refer page 3-4.
