Extracted text from philips fwc 270 service manual (Ocr-read)

Page 1

1-2 MTF BOARD TRAFO PR I. BOARD TRA FO SEC. B O ARD MA IN S BO ARD (/21/22 Only) CO MBI B O ARD F R O NT B O A RD CD BOARD LOCATION OF PCBS /21 Karaoke News RDS Incredible Surround Rotary Encoder (volume control) x Jog Shuttle x V oltage Selector x Aux Input x Digital Output Headphone Socket x Line Output Subwoofer Output Surround Output Matrix Surround Loudspeakers Standby - FTD Clock Display x ECO Standby - Dark Combi - Non-Cenelec Tuner x Combi - Cenelec Tuner VERSION VARIATIONS: T ype /Versions: FWC270 Features & Board in used:

Page 2

1-3 SPECIFICATIONS GENERAL: Mains voltage : 110-127V/220-240V Switchable Mains frequency : 50/60Hz Power consumption : < 70W Active < 20W at Standby Clock accuracy : < 4 seconds per day Dimension centre unit : 265 x 310 x 365mm TUNER: FM T uning range : 87.5-108MHz Grid 100kHz IF frequency : 10.7MHz ± 20kHz Aerial input : 75 Ω coaxial Sensitivity at 26dB S/N : < 7 µV Selectivity at 600kHz bandwidth : > 25dB IF rejection : > 60dB Image rejection : > 25dB Distortion at RF=1mV, dev. 75kHz : < 3% -3dB Limiting point : < 8 µV Crosstalk at RF=1mV, dev. 40kHz : > 18dB MW T uning range : 531-1602kHz or 530-1700kHz Grid : 9kHz or 10kHz IF frequency : 450kHz ± 1kHz Aerial input : Frame aerial Sensitivity at 26dB S/N : < 4.4mV/M Selectivity at 18kHz bandwidth : > 18dB IF rejection : > 45dB Image rejection : > 28dB Distortion at RF=50mV, m=80% : < 5% AMPLIFIER: Output power : 2 x 40W 1) RMS Frequency response within -3dB : 50Hz-15kHz Dynamic Bass Boost : DBB ON, DBB 1, DBB 2, 2) Digital Sound Control : Jazz, Techno, Optimal, 2) Headphone output at 32Ω: 15mW ± 2dB Input sensitivity, R S = 600 Ω Aux / CDR : 500mV / 1.0V Mic : {3.5mV } CASSETTE RECORDER: Number of track : 2 x 2 stereo Tape speed : 4.76 cm/sec +2.5/-1.5% W ow and flutter : < 0.35% DIN Fast-wind/rewind time C60 : 130 sec Bias system : 75kHz ± 5kHz Rec/Pb frequency response within 8dB : 80Hz - 12.5kHz Signal to noise ratio Type I : > 48dBA COMPACT DISC: Measurement done at output conn. of the CDC module. Frequency response within ± 1.5dB : 20Hz - 20kHz Output level (in Vrms) : 550mV ± 2dB, R out = 100 Ω Signal/Noise ratio (A-weighted) : > 80dBA Distortion at 1kHz : < 0.003% Channel unbalance at 1kHz : ±1dB Channel separation at 1kHz : > 60dB De-emphasis : 0 or 15/50 mS (Switched on the disc) 1) 6Ω, 1kHz, 10% THD 2) Frequency response in each setting is software controlled. : Rock DBB 3 by subcode
