Philips fw d 5 service manual
This is the 100 pages manual for philips fw d 5 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips fw d 5 service manual (Ocr-read)
Page 1
1-2 LOCATION OF PC BOARDS PCS 103 796/21 /21M /22 /30 /37 Karaoke x x News x RDS x CD Text x Low Power Standby (No display) x x V oltage Selector x x Aux / CDR Input xxxxx Digital Output xxxxx Headphone Socket xxxxx Line Output xxxxx Subwoofer Output xxxxx Surround Output xxxxx S-Video Output xxxxx SCART connector x Remote Control RC2516/01 x x x Remote Control RC2567/01 x x T uner board - ECO5 Sys x xx x T uner board - Tuner 95 x VERSION VARIATIONS: T ype /Versions: FW-D5 Features & Board in used: CDC Board CDC Board AV Board 3-CDC Key Deck Keys Disc Type LED DVD Logo LED Mic & DVD open/ close Head- phone Mains Board Center / Surround Amplifier Supply Board DAC Board Primary Secondary Left/Right Amplifier
