Philips fb 735 owners manual
This is the 7 pages manual for philips fb 735 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips fb 735 owners manual (Ocr-read)
Page 1
2 English INDEX FB735 FB755 FB965 FB975 English ..................................... 3 Franais ................................... 8 Espa–ol .................................. 13 Deutsch .................................. 18 Nederlands ............................ 24 Italiano ................................... 29 Svenska ................................. 34 Dansk ..................................... 39 Suomi ..................................... 44 Portugus .............................. 49 ¶ììèîéëÀ ..............................54 Chinese ................................60
Page 2
3 English INTRODUCTION CONNECTIONS Introduction Congratulations!!! You are now a proud owner of PHILIPS HOME CINEMA SPEAKER SYSTEM which have been developed to produce superb sound for many years of listening pleasure. Please read this manual carefully before connecting your speakers. You will find a number of useful tips for getting the best sound performance out of your home cinema surround sound speaker system. Environmental notes ¥ All redundant packaging material has been omitted. The packaging is easily separable into three mono-materials: Ð cardboard (box) Ð expandable polystyrene (buffer) Ð polyethylene (bags, protective foam sheet) ¥ Your set consists of materials which can be recycled if disassembled by a specialized company. ¥ Please observe the local regulations regarding the disposal of packing materials and old equipment. Other Home Cinema Sound Products These speakers have been designed together with Philips Home Cinema Receiver range (FR735/FR755/FR960/FR970) in order to optimise performance. For more impressive bass performance these systems can be extended with a 50W (FB201*) or 100W (FB301*) subwoofer. *not available in all countries Connecting your loudspeakers Important! Always switch off your amplifier/receiver before making any connections! + – L – + R – + MAINS OUTLETS 230V 50HZ 100W MAX SWITCHED VIDEO IN/OUT MONL VCR1 OUT IN OUT SYSTEM CONTROL RC5 SURROUND SPEAKERSRLCENTER SPEAKERFRONT SPEAKERS RL IN IN RECPLAY RECPLAY TV/ AUX VCR 1AUDIO IN/OUTRL TAPE/DCC CD/V-CD ANTENNA GND FM AM 75 CENTER SPEAKER – + – +L R SURROUND SPEAKERSFRONT SPEAKERS 8 mm 1 2 3 1 2 3 8 mm Connectors on the speakers ¥ At the back of the speakers you will find two click fit or screw connectors (, a black one marked - and a red one (for the front speakers), a blue one (for the center speaker) or a grey one (for the surround speakers) marked +.¥ 100 W Front/Surround speakers have gold plated screw terminals. ¥ One of the speaker wires is usually marked with a color or a sleeve so that you can distinguish between them. ¥ In order to prevent phase problems make a habit of connecting the marked (colored) wire to the colored + speaker terminal and the unmarked wire to the black - speaker terminal. Connectors on the amplifier/receiver The speaker connections on the amplifier or receiver may be either screw connectors or click-fit connectors. ¥ At the rear of the amplifier/receiver you will find a red colored or + terminal and a black or - terminal for each speaker. ¥ Connect the marked or sleeved speaker wire to the red or + terminal, and the unmarked wire to the black or - terminal of the amplifier/receiver. ¥ After connecting the speakers, do not forget to adjust the relative sound level between the speakers, see chapter ÒAdjusting the relative speaker balanceÓ. Note: Ð Since Left/Right Front speakers are identical to the Left/ Right Surround speakers of the FB965/FB975 packages, all connectors are same code (Black/Red), speaker terminal and wire for surrounds are still Grey/Black coded.
