Philips dvdr 985 owners manual
This is the 60 pages manual for philips dvdr 985 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips dvdr 985 owners manual (Ocr-read)
Page 1
Laser safety This unit employs a laser. To prevent possible eye injury, only a qualified service person should remove the cover or attempt to service this device. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. WARNING LOCATION: INSIDE ON LASER COVERSHIELD NEVER MAKE OR CHANGE CONNECTIONS WITH THE POWER SWITCHED ON. The DVD recorder is in conformity with the EMC directive and low-voltage directive. CAUTION ONLY QUALIFIED SERVICE PERSONNEL SHOULD REMOVE THE COVER OR ATTEMPT TO SERVICE THIS DEVICE. For Customer Use: Read carefully the information located on the back of your DVD recorder and entered below the Serial N°. Retain this information for future reference. Model N°. DVDR985 Serial N°. __________________________ CAUTION VISIBLE AND INVISIBLE LASER RADIATION. WHEN OPEN AVOID EXPOSURE TO BEAM ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING UNDGÅ UDSÆTTELSE FOR STRÅLING ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES UNNGÅ EKSPONERING FOR STRÅLEN VARNING SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN VARO! AVATTAESSA OLET ALTTIINA NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE LASER SÄTEILYLLE. ÄLÄ KATSO SÄTEESEEN VORSICHT SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG WENN ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETSEN DANGER VISIBLE AND INVISIBLE LASER RADIATION. WHEN OPEN AVOID DIRECT EXPOSURE TO BEAM ATTENTION RAYONNEMENT LASER VISIBLE ET INVISIBLE EN CAS DOUVERTURE EXPOSITION DANGEREUSE AU FAISCEAU CLASS 1 LASER PRODUCT LASER Type InGaAlP semiconductor laser (DVD) AlGaAs semiconductor laser (CD) Wavelenght 660 nm (DVD) 780 nm (CD) Output Power 20 mW (DVD writing) (out of objective) 0.8 mW (DVD reading) 0.3 mW (CD reading) Beam divergence 82 degrees (DVD) 54 degrees (CD) General information Manufactured under license from Dolby Laboratories. Dolby, Pro Logic and the double-D symbol are trademarks of Dolby Laboratories. Confidential Unpublished Works. ©1992-1997 Dolby Laboratories, Inc. All rights reserved. VIDEO Plus+ and PlusCode are registered trademarks of the Gemstar Development Corporation. The Video Plus+ system is manufactured under licence from Gemstar Development Corporation. TRUSURROUND, S SR RS S , and symbol are trademarks of SRS Labs,Inc. TRUSURROUND technology is manufactured under license from SRS Labs, Inc. This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.
Page 2
English Contents Introduction DVD Video Recorder________________________________________6 Box contents_______________________________________________7 Placement _________________________________________________7 Cleaning discs ______________________________________________7 Remote control ____________________________________________7 Loading the batteries_______________________________________7 Installation Connections - back side of your DVD recorder __________________8 Connecting to the antenna____________________________________8 Connecting to a TV set ______________________________________8 S-video (Y/C) connection ___________________________________8 Video (CVBS) connection ___________________________________8 Connecting to audio equipment________________________________9 Connecting to A/V receiver or A/V amplifier with digital Multi-channel decoder______________________________________9 Connecting to a receiver equipped with two channel digital stereo (PCM) _____________________________________________9 Connecting to a receiver equipped with Dolby Pro Logic _________9 Connecting to a TV set equipped with a Dolby Pro Logic decoder __9 Connecting to a receiver with two channel analogue stereo _______9 Connecting to other equipment ______________________________10 Connections - frontside of your DVD recorder __________________10 Camcorder connection ____________________________________10 Power supply _____________________________________________11 Switching on ______________________________________________11 First time set-up: virgin mode ________________________________11 Automatic setting ________________________________________11 Manual setting ___________________________________________12 Functional overview Front of recorder __________________________________________14 Rear of recorder___________________________________________15 Display___________________________________________________16 Remote control ___________________________________________17 Operation Important notes for operation ________________________________18 Loading discs ______________________________________________18 Disc types _______________________________________________18 The following disc types can be used for recording and playback __18 The following disc types can be used for playback only __________18 The following disc types cannot be used at all, neither for recording nor for playback _________________________________19 On-screen display information ________________________________19 System menu bar _________________________________________19 User preference menu operation ____________________________20 Status box ______________________________________________20 Tuner info box __________________________________________21 Timer info box __________________________________________21 Warning box ____________________________________________21 Index Picture Screen________________________________________22 User preferences __________________________________________23 Setting user preferences __________________________________23 Picture settings __________________________________________23 Sound settings ___________________________________________23 CONTENTS3 01DVDR985UMUKGB24451F3 21-01-2002 15:02 Pagina 3
