Audio 3rd generation Compact Disc Recording

Service
Service
Servrce

[flfigfi @figfi @EWSTE [flfiEffi
DIGITALAIJDID nisimLAunio DIGITALAUDID DIGITALAUDIU
EeWritam Recordable

Reertable

Concerning the third generation of Digital Audio Compact Disc
Recordable and Rewritable (reference set is CDR775)
Contents Page Contents Page
1 Introduction 2 - - Focus control 39
2 New in the 3rd generation sets 3 - - Radial control 40
2.1 Audio Buffer 4 - - Initialisation control 40
2.2 Improved STOP modes 5 - - The OPC 42
2.3 Analogue CD Sync. 6 - - Position Control Sledge 45
2.4 Sample Flate Converter (SRC) 7 - Clock generation 52
2.5 Direct Line Recording (DLR) 8 - Decoding and encoding (CDRGO) 54
2.6 Easyjog knob 10 3.5 Audio signal processing processing part 65
2.7 CD Text editing (input, playback) 12 - DASP 65
2.8 Automatic Fadevin / Fade-out 13 - Audio conversion A/D and D/A
3 CD Fi-RW audio recorder 14 (Codec UDA1341TS) 66
3.1 Blockdiagrams 15 4 Menu functions 74
32 Abbreviations and used terms 18 5 Power supply unit 20PSS17 82
3.3 Proces functions 26
3.4 Basic Engine 29

- Laser control 30

- EFMTIM 34

- AEGER2 37

- MACE2 38

- - Digital Servo block 39
©Copyright reserved 1999 Philips Consumer Electronics B.V. Eindhoven. The
Netherlands. All rights reserved. No part of this publication may be reproduced,
stored in a retrieval system or transmitted. in any term or by any means. electronic,
mechanical. photocopying, or otherwise without the prior permission oi Philips.
Published by JvO 9972 Service PaCE Printed in The Netherlands Subject to modification 3104 125 40100
