Philips az 1066 service manual
This is the 23 pages manual for philips az 1066 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from philips az 1066 service manual (Ocr-read)
Page 1
KT 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 Subscr. SET SPECIFICATION 2010-11 -26 1 CDSM WITH 2 AZ1066/93 3 Name: Supers: Tot.Sh.: 8 Sh. 190 - 2 A4 KT Check: Date: © PHILIPS Electronics Hong Kong Ltd., BU- PORTABLE AUDIO General description: AZ1066- PORTABLE CD SOUNDMACHINE TUNER \ 1 LIFETIME : 5 YEARS (ACC. TO UAN-D1611) 2 PERFORMANCE CLASSES : TUNER SUPPLY, AMPLIFIER SPEAKER BOXES RECORDER CLOCK CD DCC TELEPHONE REC. PLAYER I x x x 3 II x 4 III 5 SAFETY REQUIREMENTS: GB8898-2001 For /93 6 RADIATION, IMMUNITY REQUIREMENTS: (EMC) GB13837-2003 GB17625.1-2003 For / 93 7 CLIMATIC REQUIREMENTS: (acc. to UAN-D1590) All climates: -10 ° C till +50 ° C (Functional); Set has to be pre-c onditioned for 2 hour, except CD function 8 For all measurements: 25 ° C 9 POWER SUPPLY: MAINS (AC) operation DC (int. or ext.) operation / Backup Buffer Voltage selection: Battery type: R14 x 6; nom.: 9V limit : 6V5 10 Selection: See table below Lifetime: CD hours, TU 20hours (50mW, R14 batteries) 11 Frequency: External DC: No 12 POWER CONSUMPTION: Standby: Less than 1.5W Standby: 13 Maximum: 12W Maximum: 14 General : Q and R according to production division rules : Q < 1% (Major), Q < 4% (Minor) Measured according to: R < 3% (CE52) DERIVED VERSIONS: APPROBATION 15 Versio n Voltage on typeplate Tolerance Frequency Tuner 93 230V, 50Hz 10% (207V – 253V); 50Hz FM, MW (China) REMARKS: 16 TUNER PART TECHNICAL description:
Page 2
KT 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 Subscr. SET SPECIFICATION 2010-11 -26 1 CDSM WITH 2 AZ1066/93 3 Name: Supers: Tot.Sh.: 8 Sh. 190 - 3 A4 KT Check: Date: © PHILIPS Electronics Hong Kong Ltd., BU- PORTABLE AUDIO AM (circuitry) FM AM (active components) FM RF SA2111NG SA2111NG 1 IF SA2111NG SA2111NG 2 Detector QD 3 Decoder SA2111NG 4 GENERAL part: WAVE RANGE TOLERANCES TUNING 5 FM 87.5MHz - 0.3 MHz 1MHz 6 108MHz + 0.5 MHz 1MHz 7 MW 526kHz - 20KHz 5%KHz 8 1606KHz + 50KHz 5%KHz 9 10 AERIAL: MW Ferrite : Φ10 mm× 70 mm FM telescope - 540 mm 12 FM wire : N/A Execution - Rotational 180 ° 13 INDICATORS: Pointer stroke: Execution pointer: 14 Knob indication over: Field Strength: 15 ELECTRICAL DATA: AM: nom. limit FM: nom. limit 16 -3dB limiting point 20 26 dBf 17 Amplification reserve -2 -6 dB Amplification reserve 0 -4 dB 18 AGC figure of merit 30 25 dB AFC holding range - 19 Distortion (RF 50mV, m=80%) 3 5 % Distortion (RF 1mV, Δ f 67.5kHz) 1 7 % 20 Stereo -46dB quieting 48 52 21 22 Cross-talk (RF 1mV, Δ f 40kHz, 1kHz) 25 20 dB 23 IF 465 ±5kHz IF 10.7 ± 0.02MHz 24 wave range Sensitivity for 50mW noise limited sensitivity (26dB) Image rejectio n IF rejectio n large signal FM nom. 18 24 55 122dB f 25 lim. 22 20 50 111dB f 26 MW nom. 65 32 34 120dB 27 lim. 72 28 24 114dB 28 29 30 31 unit μV/m μV dBf dBμ V/m dBf dB dB dB mV/m REMARKS: \ SUPPLY, AF-AMPLIFIER & LOUDSPEAKER (Boxes) PART : TECHNICAL description:
