Philips az 1020 owners manual

Page 2

Mains plug

This apparatus is fitted with an approved moulded 13

Amp plugt To change a fuse in this type of plug

proceed as follows:

- Remove luse cover and fuse.

- For new fuse which should he 3 381352 5 Amp.
ASIA. or 381 approved type.

i 0 Reid the fuse cover.

If the fitted plug is not suitable for your socket

outlets. it should be cut off and an appropriate plug

fitted in its place,

If the mains plug contains a fuse. this should have a

value of 5 Amp. If a plug without a fuse is used, the

fuse at the distribution board should not be greater

than 5 Amp.

Note: The severed plug must be disposed to avoid a

possible shock hazard should it be inserted into a

13 Amp socket elsewhere

How to connect a plug

The wires in the mains lead are coloured with the

following code: blue = neutral (N). brown = live (L).

As these colours may not correspond with the colour

markings identifying the terminals in your plug,

proceed as follows:

- Connect the blue wire to the terminal marked N or
coloured black

0 Connect the brown wire to the terminal marked L
or coloured reds

- Do not connect either wire to the eanh terminal in
the plug, marked E (or 4-) or coloured green (or
green and yellow].

Before replacing the plug cover, make certain that the

cord grip is clamped over the sheath of the lead - not

simply over the two wiresCopyrrght in the U.K.:

Recording and playback of material may require

consent. See Copyright Act 1956 and The Performers

Protection Acts 1958 to 1972.

® Norge

Advarsel: For a redusere faren for brann eller elektrisk stat;
skal apparatet ikke utsettes for regn eller fuktighet
Typeskilt finnes pa apparatens underside.

Observer: Nettbryteren er sekundert innkoplet. Den
innebygde netdelen er derlor ikke irakoplet nettet sa lenge
apparatet er tilsluttet nettkontakten

(D Italia

DICHIARAZIONE DI BONFOBMITA

________...___._____
Si dichiara che l'apparecchio AZ 1021] Philips risponde
alle prescnzioni dell'an. 2 comma 1 del D. M. 23 Agosto

1935 n. 548. I - i

Fatto a Eindhoven. il 1 1B0l1998

Philips Sound Kt Vision
Philips, Glaslaan 2. SPF 10
5616 JB Eindhoven, The Netherlands

Important notes for users in the U.K.

English 4

_._____-/

Frangais 13

Espafiol

L

,-------h-*

Italiano 49

_. #11
Portugués as

/-----_-

Dansk ..

Svenska 7e

r-t

Suomi 35

'EMnVIKé .. 94

l

I H Francais H English l

fin

5H ltaliann HuedenanusH Dautsch H Espa

l I Svenska l l Dansk l l Ponugu

Euumi

ll

k_______~__._/

['EanrKd

N
