Z Series Specialty Components

[1 mo

Features

30 watts per channel into 89

45 watts per channel into 49

90 watts bridged into 89 mono

Gain controls and bridge switch on rear panel
Automatic onloFf by DC trigger or audio signal
Ground lift switch

Looping line output connectors

Headphone jack

LED indicators forAC present and operating mode
Gold-plated RCA input jacks and 5-way speaker terminals
High-currentTorrodial power supply

9-l/2" wide front panel; l rack space high
Fastening hardware available for rack mounting
Parasound's IO years parts, 5 years labor warranty

Born of the original Zamp, Parasound's new-
generation Zamp v.2 offers a host of new features
including loop out jacks,ground lift. audio and DC
triggering, and a sleek. smooth modern skin.Two
discrete channels of 30 watts each offer the power
to propel desktop, game.tv and distributed home
audio systems way past "good enough" and far into
the "WOW" zone. Start with just one; we'll be here

when you want more!

What is Parasound's Z-Series? It's the highest-
fidelity set of matched miniatures available today.
Only 2" tall and 9-I/2" wide,Z's can stand alone on
the smallest surface. or rack mount side by side.
Wherever you want a minimum-size system with
maximum-quality sound - on desktop. counter. in-
wall or multi-zone - the Z-Series is your compact

sonic solution.

Specifications
Continuous power output:
30 wads RMS x 2, 20 Hz - 20 kHz, 89, both channels driven
45 watts RMS x 2, 20 Hz - 20 kHz, 49, both channels driven
75 watts RMS x |,20 Hz - 20 kHz, 89, minimum impedance
Current capacity: 10 amperes peak per channel
Frequency response25 Hz - |00 kHz,+0/-3 dB
Total harmonic distortion: < 0.06 % full power;
< 0.03 % typical levels
IM distortion: < 0.03 %
Dynamic headroom: > |.5 dB
Inter-channel crosstalk: > 80 dB at l kHz; > 60 dB at 20 kHz
Input impedance: 33 k9
S/N ratio: > |00 dB, input shorted, IHFA weighted
Dimensions: 9-l/2" w x 2" h x 7" d, l-3/4" h without feet

Shipping weight: 9 lbs.

PARASOUND

Parasaund Products, Inc. 950 Battery Street, San Franciscu, CA 94111
415-397-7100 / FAX 415-397-0144 www.parawund.cam
