H'g/J Current Amplfiers

Parasounds High Current Amplifiers offer explosive power with uncompromised sound quality. Our focus on
a high current/high bias design influenced by John Curl, utilizes complimentary discrete circuitry to assure every
watt is crystal clear and available for crisp vocals, magnificent explosions, and dynamic music. Each amplifier features
l2 volt DC triggers, gain controls, and bullet-proof protection for ease of use and peace of mind. Give us the most

demanding music or the most action packed soundtrack, and you will love what you hear.

Features Specifications
Circuitry designed by john Curl Continuous power output:
Lucasfilm HomeTHX Ultra certified |25 watts RMS x 2,20 Hz - 20 kHz, 89, both channels driven
High bias Class A/AB operation 200 watts RMS x 2,20 Hz - 20 kHz, 482, both channels driven
Direct Coupled - no capacitors or inductors in signal path 400 watts RMS x I,20 Hz - 20 kHz, 89
Input stage uses hand matched complementary jFETs Current capacity: 45 amperes peak per channel
I2 beta-matched I5 amp, 50 MHz bipolar output transistors Power bandwidth: 5 Hz - I00 kHz, +0/-3 dB at I watt
Massive 785 VA toroid power transformer with Total harmonic distortion: < 0.03 % at full power
independent secondary windings for each channel IM distortion: < 003 %
40,000 HF power supply filter capacitance Slew rate: > I 30V/psecond
Independent power supplies for each channel Dynamic headroom: > L5 dB
DC Servo and relay protection circuits lnterchannel crosstalk: > 80 dB at I kHz; > 60 dB at 20 kHz
AC present, standby/normal, current overload indicators Input sensitivity: | V for 28:28V,THX Reference Level
Gold plated RCA input jacks, loop output jacks Input impedance: 33 k9
I2 volt DC automatic turn-on circuitry S/N ratio: > I I6 dB, full power; > 96 dB,THX Reference
Heavy duty 24k 5-way speaker binding posts Damping factor: > 800 at 20 Hz
Rear mounted gain controls; ground lift switch Dimensions: I7-I/4II w x 4" h x I3-I/4" d, 3-I/2" h without feet
Rack mounting adapter available Net weight: 22 lbs.

Parasounds I0 years parts, 5 years labor warranty
