Panasonic wj mx 50 service manual
This is the 110 pages manual for panasonic wj mx 50 service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic wj mx 50 service manual (Ocr-read)
Page 2
Digital Effects :
Matte Colours :
Wipe Patterns:
Joystick Control :
Audio Mixer :
Others :
Video Sampling :
Frequency Range :
Frequency Responce:
Gain :
S/N (Typical):
Differential Gain :
Differential Phase:
Power Source :
Power Consumption:
Ambient Operating Temperature:
Ambient Operating Humidity:
Dimensions 1
Wight:
Nega, Mosaic, Mono, Paint, Still, Strobe, Multi, Trail, A/V Synchro, Frame
Colour Bar, White, Yellow, Cyan, Green, Magenta, Red, Blue, Black
287 Patterns
Positioner, Colour Correction.
Aebus, B-bus, AUX-i,AU><-2, Mic, Master.
Audio»Fc|low, Auto-Take, Auto-Fade, Memory, Special Mode.
4 : i i 1, Y =14.3 MHz (936 fH), 87bit component
Sync; 15.625 KHziBOO HZ
SC, 4.433619 MHZi4U HZ
Y/C signal; 4.5 MHz (at -3dB)
Composite Video Signal; 45 MHz (at -3dB)
Audio; 20 , 20 KHz (at -3 dB)
Unity (Video)
56 dB (S-Video), 50 dB (Composite), 70dB (Audio at 1 KHz)
i5 (Composite)
it) 7. (Composrte)
220 - 240V AC 50 Hz
Operation mode; Approximately 45W
Stand-by mode; Approximately 5W
0 v 40°C
Less than 90%.
480 (W)><164 (H)><396 (D) mm
6.8 Kg
Weight and dimensions indicated above are approximate.
Specifications are subject to change without notice
