Panasonic sv sd 300 eb service manual
This is the 42 pages manual for panasonic sv sd 300 eb service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic sv sd 300 eb service manual (Ocr-read)
Page 1
2 TABLE OF CONTENTS PA G E PA G E 1 Safety Precaution-------------------------------------------------3 1.1. Supply of Rechargeable Battery as Replacement Parts ---------------------------------------- 3 1.2. Caution in use of Rechargeable Battery ------------- 3 2Warning--------------------------------------------------------------4 2.1. Caution for AC Mains Lead(For EB/GH) ------------- 4 3 Service Navigation------------------------------------------------5 3.1. About Lead Free Solder (PbF)--------------------------5 4 Specifications------------------------------------------------------5 5 Location of Controls and Components--------------------6 5.1. Accessories -------------------------------------------------- 6 5.2. Location of Controls --------------------------------------- 6 6 Service Mode-------------------------------------------------------7 6.1. Before Entering The Service Mode --------------------7 6.2. Entering The Service Mode -----------------------------7 6.3. SERVICE 1LCD Display Mode Switching------------9 6.4. SERVICE 2Device Key Serial NumberDisplay ----- 9 6.5. SERVICE 3Battery Capacity Display and Control Button Operation Check --------------------- 10 6.6. SERVICE 4Model and Region Display ------------- 11 6.7. SERVICE 8Card Recognition Operation Check ------------------------------------------------------- 11 6.8. SERVICE 9Audio Playback Check ------------------ 12 6.9. SERVICE 10Voice Playback Check(SV- SD350V only) --------------------------------------------- 12 6.10. SERVICE 11Voice Recording Check(SV- SD350V only) --------------------------------------------- 13 6.11. SERVICE 12FM Recording Check(SV- SD350V only) --------------------------------------------- 14 6.12. SERVICE 13Device Check ---------------------------- 15 6.13. MODELModel and Region Setting------------------- 15 6.14. Error Code Table ----------------------------------------- 16 7 Service Fixture & Tools---------------------------------------19 7.1. Service Position ------------------------------------------ 19 8 Disassembly and Assembly Instructions---------------20 8.1. Removal of the front cabinet unit and rear cabinet unit------------------------------------------------- 20 8.2. Removal of the Sub P.C.B. ---------------------------- 21 8.3. Removal of the LCD ------------------------------------- 21 8.4. Removal of the Main P.C.B. --------------------------- 21
Page 2
3 1 Safety Precaution 1.1. Supply of Rechargeable Battery as Replacement Parts Please take note of the following points relating to Carrying Case to be used for protection of Rechargeable Battery from shorting. Replacement Parts: - Rechargeable Battery (RFKFHAZ10EM1) to be supplied will be provided with Carrying Case. - No replacement parts will be supplied for Rechargeable Bat- tery without Carrying Case. - Replacement parts will be supplied for Carrying Case (RFA0475-Q) without Rechargeable Battery. - To your customers, delivery Rechargeable Battery together with Carrying Case to prevent shorting accidents that may occur when Rechargeable Battery is carried about without Carrying Case. 1.2. Caution in use of Rechargeable Battery - Take Rechargeable Battery out of Carrying Case and use it. - Be sure to carry Rechargeable Battery in this Carrying Case. If not, may either heat or ignite by shorting with a metal.
