Panasonic sl sx 388 owners manual
This is the 8 pages manual for panasonic sl sx 388 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic sl sx 388 owners manual (Ocr-read)
Page 1
H O L D VOL E QMEMORY/RECALL MODE OPEN D BBCC AE F H G KJ I DC IN 4.5VK M L OPEN H O L D N A B H EQ HOLD VOL A BC F G D E This function causes the unit to ignore short, accidental button presses. (The disc lid can still be opened and closed.) The HOLD function prevents the following: ≥The unit is powered on accidentally when not in use, causing the batteries to run down. ≥A button is accidentally pressed during play, interrupting the operation. To use the HOLD functionSet [HOLD] to the HOLD position. The unit and wired remote control have HOLD functions, each of which works independently. ( indicationWhen the unit is in HOLD mode, press- ing any button causes the indication ( to appear on the display. When the unit is powered offThe ( indication appears only when [ 1/;] (main unit) is pressed. 2 Power Supply Preparations Refer to the specifications (page 8) for information on operating times when using dry cell batteries. Using the AC adaptor (not included) Use only the recommended AC adaptor. Use of other AC adaptors can damage the unit. Connect the AC adaptor. Conserving powerTo save power when the unit is not to be used for a long time, unplug the AC adaptor from the household AC outlet. Reprogram tracks if necessary before use. Note!Turn the unit off before connecting or disconnecting the AC adaptor. Using dry cell batteries (not included) Insert two LR6, AA, UM-3 alkaline bat- teries. Battery indicator This indicator flashes when the batteries are almost out of power. Power is cut off completely a short while later. Replace batteries with new ones. Note!The length of time the unit will continue to operate be- tween when the battery indicator starts flashing and when the power is cut off differs depending on the type of batteries used. Using the car adaptor (not included) Use only the recommended car adaptor. Use of other car adaptors can damage the unit. Be sure to obtain the car adaptor (SH-CDC9) available as an optional accessory. Removing batteries Push up on the battery in the direction indicat- ed by the arrow. Then lift it out. If the battery lid comes loose Slide the lid back into place horizontally. If the unit malfunctions or freezes during use, disconnect the power source (the AC adaptor or batteries). Re-connect the power source and continue op- eration. O P EN 1 O P E N+- 2 3 DC IN 4.5VK CAUTION:Use only car adaptor, Model: SH-CDC9 manufac- tured by Matsushita Electric Industrial Co.,Ltd. DC IN jack (DC IN 4.5 V K) Back panel of the unitHousehold AC outlet AC adaptor O P E N O P E N S-XBS TRAIN RANDOM VOL 1 M C Battery indicator Location of Controls Portable CD Player A AStop/operation off button (∫) BSkip/search buttons (:, 9) CHeadphone volume control buttons (j,VOL, i) DEQ button (EQ) EDisplay FMode button (MODE) GMemory/recall button (MEMORY/RECALL) HPlay/pause button (1/;) IOpen switch (OPEN 1) JHeadphone jack (Ë) KHold switch (HOLD) LHole for car mounting base MDC IN jack (DC IN 4.5 V K) NCD release button (PUSH) Wired remote control B ASkip/search buttons (:, 9) BPlay/stop/operation off button (∫/1) CVolume control buttons (j, VOL, i) DHeadphone jack/ earphone jack EClip FHold switch (HOLD) GEQ button (EQ) HPlug OPEN H O L D V O L EQMEMORY/RECALL MODE HOLD EQ HOLD HOLD Back panel of the unit HOLD modeBefore operating the buttons Be sure to move [HOLD] to release the unit from the HOLD mode. HOLD Function For U.S.A. To order the optional AC adaptorRP-AC46contact 1- 800-332-5368 or web site (http://www.panasonic.com). For Canada Be sure to obtain the optional AC adaptor RP-AC46. It is available through your Panasonic dealer. Note!The dry cell batteries should be changed when the unit is off. Using rechargeable batteries (not included) ≥If rechargeable batteries are to be used, rechargeable batteries manufactured by Panasonic are recommended. ≥This unit cannot recharge batteries. The battery indi- cator will not function correctly when using recharge- able batteries. SL-SX390 SL-SX390 SL-SX390 SL-SX390
Page 2
Button Display/reference 3 Operation To pause play To stop play To turn off the unit Skip forward/ backward (skip function) Rapid forward/ backward (search function) Off mode Stop mode Sequential Play Basic Play Follow steps 1–5.In step 2:Connect the stereo headphones/earphones and wired remote control (SL-SX390) to the headphone jack [Ë]. (Plug in firmly.) In step 5:The volume range is 0-25. Press and hold to change the volume successively. The volume changes when pressed while the level is displayed. If any other display is shown, it changes to show the current level. (The volume returns to 10 when you disconnect the power source.) ≥Play stops automatically when all the tracks have been played. ≥If the unit has been connected to the car audio system, set this units volume to 10, then adjust the volume level on the system. For your reference: ) indication This indication appears for about 30 seconds if [1/;] is pressed when no disc is loaded in the unit or if the disc is not properly secured. * indicationThis indication appears for about 10 minutes when the cover is opened. (However, the indication does not ap- pear when the unit is powered off.) Removing discs1 Press [∫] to stop play and disc rotation. 2 Slide [OPEN 1] to open the lid. 3 Press [PUSH] to release the disc. Do not stop the disc by hand or try to remove it before it stops rotating. This can damage CDs. Note!Never insert foreign objects into the unit. Auto power off functionIf the unit is left in stop mode for approximately 10 min- utes, the unit powers itself off automatically in order to prevent the battery from running down. (If no disc is loaded in the unit, it powers itself off in about 30 seconds.) ≥During program play (page 4), these buttons are used to skip forward or backward through the programmed sequence of tracks. ≥You cannot skip to tracks that have been played in random or random repeat play (page 4). ≥During program play, 1-track repeat play, random play and random repeat play (page 4), search op- eration is limited to the current track only. Press during play. Press during play. Press during stop mode. Press during play. (Press [:] twice to skip to the beginning of the previous tracks.)Press again to restart play. Press and hold during play. OPEN H O L D PUSHPUSH 3 HOLD 4 S-XBS TRAIN RANDOM VOL 1 M C 5 S-XBS TRAIN RANDOM VOL 1 M C VOL HOLD V O L EQM E M O R Y/R E C A L L M O D E OPEN 1 OPEN OPEN H O L D 2 L R VOL Label must face upward. Track number in play Elapsed playing time of each track Backward Forward S-XBSTRAIN RANDOM VOL1M C S-XBSTRAIN RANDOM VOL1M C S-XBSTRAIN RANDOM VOL1M CS-XBSTRAIN RANDOM VOL1M C Total number of tracks Total playing timePlug type: 3.5 mm (1/8 in.) stereo Resume function notes≥Opening the lid while in the stop mode or replacing the disc while in the off mode cancels the function. (It may re- main active if you replace a disc in the off mode.) ≥Play may resume from the beginning of the next track if you stopped play near the end of a track. ≥The resume function works automatically and cannot be turned off. Increase Decrease Note on CD-R and CD-RWThis unit can play CD-DA format audio CD-R and CD-RW that have been finalized §upon completion of recording. It may not be able to play some CD-R or CD-RW due to the condition of the recording. §Finalizing is a process that enables CD-R/CD-RW players to play audio CD-R and CD-RW. Close the lid. No indicator is shown. Resume functionPlay starts from the beginning of the current track the next time you press [1/;]. SL-SX390
