Page 1
2 IMPORTANT SAFETY INSTRUCTIONS 1.Power source-Connect the unit to a power source of the type described in these instructions or as marked on the unit. 2. Polarization-The unit is equipped with a polarized power plug where one blade is wider than the other. This safety feature ensures that the plug fits into your household AC outlet only one way. If the plug doesnt fit one way, try reversing it. If the plug still doesnt fit, contact an electrician to replace the obsolete outlet. Do not attempt to defeat the safety purpose of the plug. 3. Power cord protection-Route the AC power supply cord so that it will not be walked on or pinched by items placed on or against it. Never take hold of the plug or cord with wet hands. Always grasp the plug body firmly when connecting and disconnecting it. 4. Overloading-When connecting the AC power supply cord, be careful not to overload the household AC outlet, extension cord, or outlet from any other device as this can result in fire or electric shock. 5.Nonuse periods-Turn the unit off when it is not in use. Unplug the unit from the household AC outlet if it is not to be used for a long time. Unplug the unit during lightning storms. Leaving the unit connected to a household AC outlet for extended periods can cause battery fluid leakage. 6. Attachments and accessories-Use only the attachments and accessories recommended in these operating instructions. ∫Placement1. Foreign material-Ensure objects and liquids do not get into the unit. Avoid exposing the unit to excessive smoke, dust, mechanical vibration, and shock. 2. Magnetism- Situate the unit away from equipment and devices that generate strong magnetic fields. 3. Stacking-Do not place anything on top of this unit. 4. Wall and ceiling mounting-Do not mount the unit on walls or ceilings unless specified in the instructions. ∫Environment1. Water and moisture-Do not use the unit near water, such as near a bathtub or swimming pool. Avoid damp basements. 2. Heat- Situate the unit away from heat sources, such as radiators. Do not leave it in an automobile exposed to direct sunlight with the doors and windows closed as this may deform the cabinet. 2.Do not situate where temperatures fall below 5 eC (41 eF) or rise above 35 eC (95 eF). Unplug the unit from the household AC outlet before cleaning. Clean with a damp cloth. Do not use abrasive pads, scouring powders, or solvents. 1. Damage requiring service-The unit should be serviced by qualified service personnel if: 1.(a) The AC power supply cord or AC adaptor has been damaged; or 1.(b) Objects or liquids have gotten into the unit; or 1.(c) The unit has been exposed to rain; or 1.(d) The unit does not operate normally or exhibits a marked change in performance; or 1.(e) The unit has been dropped or the cabinet damaged. 2. Servicing-Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel. 3. Replacement parts-When parts need replacing ensure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may result in fire, electric shock, or other hazards. 4.Safety check-After repairs or service, ask the servicer to perform safety checks to confirm that the unit is in proper working condition. Safety Installation Maintenance Service Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the safety precautions listed below. Keep these operating instructions handy for future reference. CAUTION!THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL. Marking sign is located on bottom of the unit. WARNING:TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PRODUCT DAMAGE, DO NOT EXPOSE THIS APPARATUS TO RAIN, MOISTURE, DRIPPING OR SPLASHING AND THAT NO OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE APPARATUS. CAUTION: (SL-SW940) Use only car adaptor, Model: SH-CDC9 manufactured by Matsushita Electric Industrial Co., Ltd. THE FOLLOWING APPLIES ONLY IN THE U.S.A. CAUTION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ≥Reorient or relocate the receiving antenna. ≥Increase the separation between the equipment and receiver. ≥Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ≥Consult the dealer or an experienced radio/TV technician for help. Any unauthorized changes or modifications to this equipment would void the users authority to operate this device. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. ONLY FOR U.S.A. Panasonic Consumer Electronics Company, Division of Matsushita Electric Corporation of America One Panasonic Way Secaucus, New Jersey 07094Panasonic Sales Company, Division of Matsushita Electric of Puerto Rico, Inc. Ave. 65 de Infantería, Km. 9.5 San Gabriel Industrial Park, Carolina, Puerto Rico 00985 Panasonic Portable Audio Products Limited Warranty Limited Warranty CoverageIf your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer Electronics Company or Panasonic Sales Company (collectively referred to as the warrantor) will, for the length of the period indicated on the chart below, which starts with the date of original purchase (warranty period), at its option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished product. The decision to repair or replace will be made by the warrantor. Product or Part Name All Portable Audio Products except item listed below Rechargeable batteries (in exchange for defective item) Parts One (1) Year Ten (10) Days Labor One (1) Year Not applicable During the Labor warranty period there will be no charge for labor. During the Parts warranty period, there will be no charge for parts. You must mail-in your product during the warranty period. This Limited Warranty excludes both parts and labor for batteries, antennas, and cosmetic parts (cabinet). This warranty only applies to products purchased and serviced in the United States or Puerto Rico. This warranty is extended only to the original purchaser of a new product which was not sold as is. Mail-In ServiceFor assistance in the continental U.S.A. in obtaining repairs please ship the product to: Panasonic Services Company Customer Servicenter Suite B 4900 George McVay Drive McAllen, TX 78503 For assistance in Puerto Rico call Panasonic Sales Company (787)-750-4300 or fax (787)-768-2910. When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the original carton. Include a letter detailing the complaint and provide a day time phone number where you can be reached. Customer Services Directory For Product Information, Operating Assistance, Literature Request, Dealer Locations, and all Customer Service inquiries please contact: 1-800-211-PANA (7262), Monday–Friday 9 am–9 pm; Saturday–Sunday 9 am–7 pm, EST. or send e-mail: consumerproducts@panasonic.com For hearing or speech impaired TTY users, TTY: 1-877-833-8855 Web Site: http://www.panasonic.com You can purchase parts, accessories or locate your nearest servicenter by visiting our Web Site. IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD THE PURCHASER WILL BE REQUIRED TO FURNISHA SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID AND PLACE OFPURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCHPROOF OF PURCHASE.Limited Warranty Limits And ExclusionsThis warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in shipment, or failures which are caused by products not supplied by the warrantor, or failures which result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments, misadjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification, introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other business or rental use of the product, or service by anyone other than a Factory Servicenter or other Authorized Servicer, or damage that is attributable to acts of God. THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER LIMITED WARRANTY COVERAGE. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY.(As examples, this excludes damages for lost time, travel to and from the servicer, loss of or damage to media or images, data or other memory or recorded content. The items listed are not exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED WARRANTY. Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the exclusions may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. If a problem with this product develops during or after the warranty period, you may contact your dealer or Servicenter. If the problem is not handled to your satisfaction, then write to the warrantors Consumer Affairs Department at the addresses listed for the warrantor. PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR RESPONSIBILITY. Service in Puerto Rico Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company/Factory Servicenter: Ave. 65 de Infanteria, Km. 9.5, San Gabriel Industrial Park, Carolina, Puerto Rico 00985 Phone (787) 750-4300 Fax (787) 768-2910 Accessory Purchases: 1-800-332-5368 (Customer Orders Only) For hearing or speech impaired TTY users, TTY: 1-866-605-1277 Panasonic Services Company 20421 84th Avenue South, Kent, WA 98032 (6 am to 5 pm Monday–Friday; 6 am to 10:30 am Saturday; PST) (Visa, MasterCard, Discover Card, American Express, Check) F0402NY1082 DATE OF PURCHASE DEALER NAME DEALER ADDRESS TELEPHONE NUMBER User memo:
Page 2
Household AC outlet A Location of controls/Connection to other equipment Turn off this unit and the other equipment before connection. Battery compartment Hold switch Headphone jackLock/ Lock release Stop/Operation off ∫To DC IN jack Display panel Volume control Skip/Search Play mode selection Program /Recall Headphones Audio system Adjust the volume level on the audio system. AC adaptor (RP-AC46)(not included) To CD or AUX terminals Car stereo cassette adaptor (Purchase SH-CDM10Afor SL-SW940) ≥ Set the units volume to 10. Tone selection Some cannot be connected. Car audio 3 Lens Supplied Accessories ≥1 Pair of stereo headphones : L0BAD0000160 (gray)or L0BAD0000161 (blue) ≥1 Hand strap : RGQT0006-K1SL-SW941C ONLY ≥1 Car power adaptor: SH-CDC12PEY ≥1 Car stereo cassette adaptor:SHCDM10B1PYK Check the packing carton for these accessories. Use numbers indicated when ordering replacements or optional accessories from your Panasonic dealer.In the U.S.A.contact 1-800-332-5368 or the website (http://www.panasonic.com). Play /Pause Car power adaptor (Purchase SH-CDC9for SL-SW940) ≥ When you switch off the car, the volume returns to 10. ≥ You can recharge the batteries with this connection. ∫To Headphone jack Audio cable (not included) ≥ Set the units volume to 10. Hand strap While jogging, hold the unit as shown.Bottom of the unit As a safety precaution this unit is constructed so it is impossible to recharge ordinary batteries. For details, check with your dealer. Special rechargeable Ni-Cd batteries:P-3GAVA/2B (set of 2) Ordinary dry cell batteries/ rechargeable batteries Power Supply How to Use Rechargeable batteries (not included) Recharge before initial use. 1 2 3 ∫The battery indicator ( ) scrolls while recharging and disappears when finished (about 6 hours). ∫You can recharge the batteries before they are fully discharged. ∫Fit the battery lid so it is secure and flush with the battery compartment if it comes loose, otherwise it can scratch your discs. ∫To remove the batteries, lift from the left. Dry cell batteries (not included) After disconnecting the AC adaptor, insert two LR6, AA, UM–3 alkaline batteries. Insert the same way as the rechargeable batteries. The battery indicator DC IN jack 2:5 2 2 The unit switches off shortly after the indicator starts flashing. This indicator appears when the unit is on. AC adaptor (Optional: RP-AC46) Household AC outlet Opening and closing the lid ➪right Make sure the unit is off when recharging. ∫Before playing starts the battery indicator may flash although the batteries are not drained. It appears correctly once you start play. Close securely. Car adaptor The SL-SW941C comes with a car adaptor. (Refer to the separate installation instructions.) Purchase the optional accessory car power adaptor (SH-CDC9) for use with SL-SW940. 3 4 1 2 1:1 0 5 Playback Open, insert a CD and close securely. Release HOLD. Track number Elapsed playing time of track Press. Adjust the volume.(0 - 25) Plug in firmly. Plug type: 3.5 mm (1/8 in.) stereo ∫The volume returns to 10 when you disconnect the power source. Open the lid.Close the lid. Play time ➪Specifications (page 1) ∫Attaching the hand strap ∫Optional rechargeable batteries Rubber cap Rubber cap
