2 Using the AC adaptor (not included) Use only the recommended AC adaptor. Use of other AC adaptors can damage the unit. Connect the AC adaptor. Conserving powerTo save power when the unit is not to be used for a long time, unplug the AC adaptor from the household AC outlet. Power Supply Preparations Refer to the specifications (page 8) for information on operating times when using dry cell batteries. CAUTION:Use only car adaptor, Model: SH-CDC9 manufac- tured by Matsushita Electric Industrial Co., Ltd. Battery indicator This indicator flashes when the batteries are almost out of power. Power is cut off a short while later. Replace batteries with new ones. Note! How long the unit continues to operate after the battery indicator starts flashing depends on the type of batteries and on whether you are using the unit to play CDs or the radio. Using the car adaptor (not included) Use only the recommended car adaptor. Use of other car adaptors can damage the unit. Be sure to obtain the car adaptor (SH-CDC9) available as an optional accessory. DC IN4.5V If the unit malfunctions or freezes during use, disconnect the power source (the AC adaptor or batteries). Re-connect the power source and continue operation. DC IN jack (DC IN 4.5 V K ) Back panel of the unitHousehold AC outlet AC adaptorBattery indicator C S- XBS AUTO RANDOM MEMORY FM AM VOL MONO CITY TUNED SORRY 1 M Important note about the memory and the power supply To preserve the contents of the memory, ensure the unit has a constant supply of power. ≥Turn the unit off before changing the batteries and before connecting or disconnecting the AC adaptor. ≥The unit can maintain the memory without power for about one minute. Change batteries or recon- nect the AC adaptor within this time. ≥As a precaution, insert batteries even when using the AC adaptor or car adaptor. For U.S.A. To order the optional AC adaptorRP-AC46contact 1-800-332-5368 or web site (http://www.panason- ic.com). For Canada Be sure to obtain the optional AC adaptor RP- AC46, available through your Panasonic dealer. Using dry cell batteries (not included) Insert two LR6, AA, UM-3 alkaline batteries. Note!The dry cell batteries should be changed when the unit is off. Using rechargeable batteries (not included) ≥If rechargeable batteries are to be used, rechargeable batteries manufactured by Panasonic are recommend- ed. ≥This unit cannot recharge batteries. The battery indi- cator will not function correctly when using recharge- able batteries.Removing batteries Push up on the battery in the direction indicat- ed by the arrow. Then lift it out. If the battery lid comes loose Slide the lid back into place horizontally. O P E N 1 O P E N+- 2 3 O P E N O PE N Location of Controls OPEN ËH O L D J K L M NDE G F H I B A C O DC IN4.5V P Q Ë OPEN H O L D OPR OFF M E M O R Y / R E C A L LTUNING MODE FM MODE MONO/ST 30 STATIO N M EM O RYPO R TA B LE C D PLA YE R SL-SV500 VOLVOLS-XBSRADIO/ BANDFM RECEPT CITY/NOR MODE AStop/operation off button (∫, OPR OFF) BTuning/skip/search buttons ( 9/i, :/j) CMemory/recall button (MEMORY/RECALL) DTuning mode select button (TUNING MODE) EDisplay FS-XBS button (S-XBS) GTuner on/band select button (RADIO/BAND) HHeadphone volume control buttons (VOLi, VOLj) IPlay/pause button ( 1/ ;)JSensitivity control, play mode button ( FM RECEPT%CITY/NOR, MODE) KOpen switch (OPEN1) LMonaural/stereo button (FM MODE MONO/ST) MHeadphone jack (Ë) NHold switch (HOLD) OCD release button (PUSH) PHole for car mounting base Q DC IN jack (DC IN 4.5 V K) HOLD Ë O P E N H O L D O P R O F F M E M O R Y/ R E C A LLTUNING MODE F M M O D E M O N O /S T 30 STATION MEMORYPORTABLE CD PLAYER S L - S V 5 0 0 VOLVOLS-XBSRADIO/ BANDFM RECEPT CITY/NOR MODE HOLD modeBefore operating the buttons Be sure to move [HOLD] to release the unit from the HOLD mode. This function causes the unit to ignore short, accidental button presses. (The disc lid can still be opened and closed.) The HOLD function prevents the following: ≥The unit is powered on accidentally when not in use, causing the batteries to run down. ≥A button is accidentally pressed during play, interrupting the operation. To use the HOLD functionSet [HOLD] to the HOLD position. ( indicationWhen the unit is in HOLD mode, press- ing any button causes the indication ( to appear on the display. When the unit is powered off:The ( indication appears only when [ 1/;] or [RADIO/BAND] is pressed. HOLD Function Back panel of the unit
