Page 2

owe I

pply Preparat ons

Reler to the specifications (page 6) tor intormation on operating times when using rechargeable batteries or dryvcell batteries.

Using the AC adaptor

Connect the AC adaptor supplied.
no [N jack ( 9-6-9 Dc IN 45 V)

AC power
outlet

on

The configuration of the AC adaptor dilters according to
the model.

Using rechargeable batteries

Obtain the optional rechargeable batteries tor SL-SSGO,
SL-SastC and SL-SIJSZC.

Make sure to recharge the batteries betore using them.
The unit cannot be used to charge rechargeable batter-
ies other than those specially designed lor it.

oSupplied batteries for SL-8365 (RP-BPGO)

OOptionaI batteries (P-SGAVNZB, SH-CDBBD)

Recharging procedure

1 Insert the special rechargeable bat-
teries Into the unit.

2 Connect the AC adaptor.
(Heler to Using the AC adaptor tor connection
instructions.)
Recharging stans and the G" charging indicator
llashes on and oil on the unit's display panel.
When the rechargeable batteries lully recharge the
charging indicator disappears.

3 When recharging is complete, un-
plug the AC adaptor trom the power
outlet and the DC IN jack.

Olt takes approximately 3 hours to fully recharge the
supplied rechargeable batteries. (SL-saes)

'Rechargeable batteries have a service lite of approxi-
mately 300 charge-discharge cycles. It the operating
time on one full charge becomes noticeably shorter
than it used to be, the battery has reached the end at
its service lite and should be replaced.

ORecharging may only be pertormed when the unit is
powered oil. (It is not possible to recharge the batter
ies while playing a CD.)

OThe AC adaptor and rechargeable batteries may be-
come warm while recharging is in progress. This is not
a maltunction.

It the battery lld
comes loose

Slide the lid back into
place horizontally.

Removlng batteries
Push up on the battery
in the direction indicat-
ed by the arrow, Then
lift it out.

Using dry-cell batteries
(not included)

After disconnecting the AC adaptor. insert two AA"
(LRS) alkaline batteries.

The procedure tor Inserting and removlng dry-cell
batteries to ldentlcal to that tor rechargeable bat-
teries.

Battery indicator

1 ' Batte indicator
.u llriB 'V

This indicator llashes on and all when the batteries are
almost out 01 powert Power is cut all completely a short
while laterr

Rechargeable batteries: Recharge batteries.
Dry-cell batteries: Replace batteries with new ones.

OThe length of time the unit will continue to operate be-
tween when the battery indicator stans (lashing and
when the power is cut oil diliers depending on the
type ol batteries used.

OThe battery indicator may not tlash it rechargeable
batteries, other than those designated by Panasonic.
are Used.

Using the car adaptor

The SL-SSGtC and SL-SSSZC come with a car adaptor.
Be sure to use the adaptor specially designed lor these
models.

(Refer to the separate installation instructions.)

Be sure to obtain the car adaptor (SH-CDCQ) lor SL-
8360 and SL-SSSS, available as an optional accessory.
The car adaptor can be used to recharge the unit's bat-
teries while in the car.

CAUTION: (SL-8360/SL-8365)
Use only car adaptor. Model: SH-CDCS manulac-
tured by Matsushita Electric Industrial Co.,Ltd.

It the unlt malfunctions or freezes during useV
then disconnect the power sources (the AC
adaptor and batterles).

Reconnect the power source and contlnue op-
eration.

Loco on of Controls , , ,

0 Hold switch (HOLD)

Q

Back panel ol
the unit

Portable CD player El

0 Skip/search buttons
(K4, >>l 4 . >>)

9 Display

0 Stop/power oft button
(I, POWER OFF)

0 Play/pause button (> II)

9
Remote sensor (SENSOR)

0 Repeat button (REF)

6 Memory/recall button
(MEMORY/RECALL)

0 Open button (OPEN)

0 Headphones volume control
(VOLUME)

0 AntI-shock button (A.SHOCK)

0 S-XBS button (S-XBS)

G Headphone lack (Q)

0 Play mode selector
(RESUME, NORMAL, RANDOM)

0 on release button (PUSH)

0 Out jack (OUT)

0 DC in jack
(ea-e DO IN 4.5 V)

a Hole for car Insulator mount-
ing screw

Wired remote control
SL-8365 ONLY E

o Skip/search buttons (+.-)
9 Hold switch (HOLD)

0 PIay/stoplott button

0 Plug

9 Volume control (VOL)

(3 Hold indlcator
