Page 2

ower

pply Preparat'ons

Reier to the specifications (page 8) for information on operating times when using rechargeable batteries or dry-cell batteries.

Using the AC adaptor

Connect the AC adaptor supplied.
DC lN jack ( ee-o DC IN 4.5 V)

.______2
The configuration oi the AC adaptor difiars according to
the model.

Using rechargeable batteries

Obtain the optional rechargeable batteries ior SL-Szoo
and SL-SZotC.

Make sure to recharge the batteries before using them.
The unit cannot be used to charge rechargeable batter-
ies other than those specially designed ior it.

ISupplied batteries ior SL-8205 (RP~BP60)

OOptional batteries (P-SGAVMB. SH-CDB80)

Recharging procedure

1 Insert the special rechargeable bat-
teries Into the unit.

2 Connect the Ac adaptor.

Raferto Using the AC adaptor ior connection in- '

slructions.

3 When recharging is complete, un-
plug the AC adaptor from the power
outlet and the DC IN jack.

on takes approximately 3 hours to tully recharge the
supplied rechargeable batteries.

IFtechargeable batteries have a service life oi approxi-
mately 300 chargeoischarge cycles. It the operating
time on one full charge becomes noticeably shorter
than it used to be. the battery has reached the end of
its service liie and should be replaced.

oYou can operate the unit with the AC adaptor while re-
charging the batteries. but it will lengthen the recharg-
ing time.

CTha AC adaptor and rechargeable batteries may be-
come warm while recharging is in progress. This is not
a malfunction.

It the battery lld

comes loose
Slide the lid back into
place horizontally.

Removing batter-
les

Push up on the battery
in the direction indicat-
ed by the arrow. Then
lift it out.

1*

Using the car adaptor

The SL-Szotc comes with a car adaptor. Be sure to
use the adaptor specially designed ior this model.
(Refer to the separate installation instructions.)

Be sure to obtain the car adaptor (SH-C069) for
SL-SZOO and SL-szos. available as an optional acces-
sory. The car adaptor can be used to recharge the unit's
batteries while in the car.

CAUTION: (SL-SZOO/SLSZOS)
Use only car adaptor. Model: SH»CDCS manuiac-
tured by Matsushita Electric Industrial Co.. Ltd.

Using dry-cell batteries
(not included)

After disconnecting the AC adaptor. insert two AA
(LRS) alkaline batteries.

The procedure for Inserting and removing dry-cell
batteries la Identical to that to! rechargeable bat-
tarlaa.

Battery indicator

"1 -._ Battery indicator
Iu 'itr')

This indicator flashes on and off when the batteries are
almost out of power. Power is out off completely a short
while later.

Rechargeable batterles: Recharge batteries.
Dry-cell batteries: Replace batteries with new ones.

OThe length oi time the unit will continue to operate be-
tween when the battery indicator starts flashing and
when the power is cut cit differs depending on the
type of batteries used.

ITha battery indicator may not ilash ii rechargeable
batteries. other than those designated by Panasonic.
are used.

Ii the unit maliunctlons or freezes during uso.
than disconnect the power sources (the AC
adaptor and batterlel).

Pie-connect the power source and contlnue op-
oration.

How Fund... '

HOLD mode

This iuncticn causes the unit to ignore

ho ,' d" indication

0 Back panel oi
the unit

short. accidental button presses. (The
disc lid can still be opened and closed.)

The HOLD function prevents the

following:

IPowering on the unit accidentally
(which can cause the batteries to go
dead).

OFlay being cut oii unexpectedty in the
middle oi a selection.

To use the HOLD tunctlon
Set HOLD to the HOLD position.

When the unit is in hold status. pressing
any button (other than the OPEN button)
causes the indication ha .' d" to appear
on the display.

When the unit la powered oft

The "ho ,' d" indication appears only
when D II button is pressed.

Before operating the buttons
Be sure to move HOLD to release
the unit from the hold mode.

o Skip/search buttons
(.44, ». .sKIP - SEARCH)
9 Display
6 CD release button (PUSH)
0 Play/pause button (b II)
6 Stop/power oft button
(I, POWER OFF)
0 Memory/recall button
(MEMORY/RECALL)
@Flepeat button (REPEAT)
0 Open button (OPEN)
0 Headphones volume control
(VOLUME)

0 XBS selector (X35)

0 Headphones lack (Q)

0 Play mode selector
(RESUME, NORMAL. RANDOM)

0 Hold switch (HOLD)

0 Anti-shock switch
(ANTI-SHOCK)

0 Out lack (our)

0 DC In lack
(6-6-0 DC IN 4.5 v)

0 Hole tor car Insulator mount-
lng screw
