Panasonic sl mp 35 owners manual

This is the 8 pages manual for panasonic sl mp 35 owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.

Page: 1 / 8

Extracted text from panasonic sl mp 35 owners manual (Ocr-read)

Page 1

2 Power Supply Preparations Refer to the speciﬁcations (page 8) for information on operating times when using rechargeable batteries or dry cell batteries. Using the AC adaptor (not included) Use only the recommended AC adaptor. Using other AC adaptors can damage the unit. Connect the AC adaptor. 2 Connect the AC adaptor.(Refer to Using the AC adaptor for connection instructions.) Recharging starts and the charging indicator ﬂashes on the display. When the rechargeable batteries fully recharge the charging indicator disappears. 3 When charging is complete, unplug the AC adaptor from the household AC outlet and DC IN jack. Note!≥Rechargeable batteries have a service life of approxi- mately 300 charge-discharge cycles. The batteries have reached the end of their operational life if they last for a noticeably shorter time after recharging, or if they cannot be recharged at all. Replace the batteries. ≥Recharging may only be performed when the unit is off. ≥The AC adaptor and rechargeable batteries may be- come warm while recharging is in progress. This is not a malfunction. ≥Leaving the AC adaptor connected can cause the bat- teries to go ﬂat. After recharging the batteries and dis- connecting the AC adaptor from the household AC outlet, ensure you disconnect the AC adaptor from the units [DC IN 4.5 V K ] terminal. Battery indicator This indicator ﬂashes when the batteries are almost out of power. Power is cut off completely a short while later. Rechargeable batteries:Recharge batteries. Dry cell batteries:Replace batteries with new ones. Note! ≥The length of time the unit will continue to operate be- tween when the battery indicator starts ﬂashing and when the power is cut off differs depending on the type of batteries used. ≥The battery indicator may not ﬂash if rechargeable batteries other than those designated by Panasonic are used. Using the car adaptor SL-MP36C includes a car adaptor. Refer to the sepa- rate Installation Instructions. For SL-MP35, obtain the car adaptor (SH-CDC9) avail- able as an optional accessory. The car adaptor can be used to recharge the units bat- teries while in the car. Use only the recommended car adaptor. Use of other car adaptors can damage the unit. Removing batteries Push up on the battery in the direction indicat- ed by the arrow. Then lift it out. If the battery lid comes loose Slide the lid back into place horizontally. If the unit malfunctions or freezes during use, disconnect the power source (the AC adaptor or batteries). Re-connect the power source and contin- ue operation. DC IN 4.5 VK DC IN jack (DC IN 4.5 V K) Back panel of the unitHousehold AC outlet AC adaptor O P E N O P E N TRACK ALBUMMP3 M1RND S-XBS Battery indicator Location of Controls AMemory/recall button (MEMORY) BMode button (MODE) CDisplay DS-XBS button (S-XBS) EHeadphone volume control (i, VOLUME, j) FSkip/search buttons (:, 9) GPlay/pause button (1/;) HStop/operation off button (∫) IOpen switch (OPEN 1)JAlbum skip buttons (M ALBUM L ) KDisplay button (DISPLAY) LAlbum mode button (ALBUM MODE) MHeadphone jack (Ë) NHold switch (HOLD) OCD release button (PUSH) PHole for car mounting base QDC IN jack (DC IN 4.5 V K) OPEN HOLD HOLD Conserving powerTo save power when the unit is not to be used for a long time, unplug the AC adaptor from the household AC outlet. Note!Turn the unit off before connecting or disconnecting the AC adaptor. PQ O PE N A B D E FH CEG I ML JF J K N O P E N H O L D O HOLD DC IN 4.5 VK HOLD mode This function causes the unit to ignore short, accidental button presses. (The disc lid can still be opened and closed.) The HOLD function prevents the following: ≥The unit is powered on accidentally when not in use, causing the batteries to run down. ≥A button is accidentally pressed during play, interrupting the operation. To use the HOLD functionSet [HOLD] to the HOLD position. indicationWhen the unit is in HOLD mode, pressing any button causes the indica- tion, to appear on the display. When the unit is offThe indication appears only when [1/;] is pressed. HOLD Function ≥Never mix dry cell and rechargeable batteries. ≥Turn the unit off before replacing the recharge- able batteries. Using rechargeable batteries (not included) Obtain the optional rechargeable batteries. Make sure to recharge the batteries before using them. The unit cannot be used to charge rechargeable batter- ies other than those specially designed for it. Optional batteries: P-3GAVA/2B Recharging procedure 1 Insert the special rechargeable bat- teries into the unit. Using dry cell batteries (not included) After disconnecting the AC adaptor, insert two LR6, AA, UM-3 alkaline batteries. The procedure for inserting and removing dry cell batteries is identical to that for rechargeable bat- teries. CAUTION:Use only car adaptor, Model: SH-CDC9 manufac- tured by Matsushita Electric Industrial Co., Ltd. Before operating the buttons Be sure to move [HOLD] to release the unit from the HOLD mode. O P E N 1 O P E N+- 2 3 For U.S.A To order the optional AC adaptorRP-AC46contact 1- 800-332-5368 or web site (http://www.panasonic.com). For Canada Be sure to obtain the optional AC adaptor RP-AC46. It is available through your Panasonic dealer. Back panel of the unit

Page 2

Sequential Play Basic Play 34 5 2 HOLD 1 OPEN OPEN VOLUME OPEN / TRACK ALBUM MP3 M 1 RND S-XBS L R HOLD H O L D Label must face upward. Track number in play Elapsed playing time of each track 3 Plug type: 3.5 mm (1/8 in.) stereo Close the lid. Button Display/reference Operation To pause play To stop play To turn off the unit Skip forward/ backward (skip function) Rapid forward/ backward (search function) Off mode Stop mode For your reference: indication This indication appears for about 30 seconds if [1/;] is pressed when no disc is loaded in the unit or if the disc is not properly secured. indicationThis indication appears for about 10 minutes when the lid is opened. (However, the indication does not appear when the unit is off.) Removing discs1 Press [∫] to stop play and disc rotation. 2 Slide [OPEN1] to open the lid. 3 Press [PUSH] to release the disc. Do not stop the disc by hand or try to remove it before it stops rotating. This can damage CDs. Note! Never insert foreign objects into the unit. Auto-off functionIf you leave the unit in stop mode for about 10 minutes (30 seconds if disc is not loaded), it turns off to save the batteries. OPEN PUSHPUSH H O L D ≥During program play (page 4), these buttons are used to skip forward or backward through the programmed sequence of tracks. ≥You cannot skip to tracks that have been played in random or random repeat play (page 4). ≥During program play, 1-track repeat play, random play and random repeat play (page 4), search op- eration is limited to the current track only. Press during play. Press during play. Press during stop mode. Press during play. (Press [:] twice to skip to the beginning of the previous track.)Press again to restart play. Press and hold during play. BackwardForward ALBUMMP3 M1RND S-XBS TRACK ALBUMMP3 M1RND S-XBS Total number of tracks Total playing time Resume function notes≥Opening the lid while in the stop mode or replacing the disc while in the off mode cancels the function. (It may re- main active if you replace a disc in the off mode.) ≥Play may resume from the beginning of the next track if you stopped play near the end of a track. ≥The resume function works automatically and cannot be turned off.No indicator is shown. Resume functionPlay starts from the beginning of the current track the next time you press [1/;]. Note on CD-R and CD-RWThis unit can play CD-DA format audio CD-R and CD-RW that have been ﬁnalized §upon completion of recording. It may not be able to play some CD-R or CD-RW due to the condition of the recording. §Finalizing is a process that enables CD-R/CD-RW players to play audio CD-R and CD-RW. Follow steps 1–5.In step 2:Connect the stereo headphones or stereo earphones to the [Ë] jack. (Plug in ﬁrmly.) In step 5:The volume range is 0-25. Press and hold to change the volume successively. The volume changes when pressed while the level is displayed. If any other display is shown, it changes to show the current level. ≥The music symbols ﬂash randomly during play. ≥Play stops automatically when all the tracks have been played.
