Panasonic sl j 610 v owners manual
This is the 8 pages manual for panasonic sl j 610 v owners manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic sl j 610 v owners manual (Ocr-read)
Page 1
A Main unit Remote control Location of controls/Connection to other equipment Battery compartmentHold switch Headphone jack Open switch Tuning/Skip/SearchPlay/Pause Stop/ Turn off Volume control To DC IN jack Monaural/Stereo Sound quality selection Memory/Recall/Digital Re-master/Anti-skip mode selection Audio system Adjust the volume on the audio system. AC adaptorPurchase RP-AC46 for . Connect the AC adaptor to the household AC outlet first. SL-SV570 SL-SV573J Household AC outlet Car power adaptor (SH-CDC9) (not included) You can recharge the batteries with this connection. SL-J610V Car audio To CD or AUX terminals Audio cable (not included) Car stereo cassette adaptor(SH-CDM10A) (not included ) Sensitivity control/ Play mode selection Some cannot be connected. 2 Lens ≥1 AC adaptor: RFEA403C-2S ≥1 Active speaker system: Speaker (R ch): RFKNLJ610VP1 Speaker (L ch): RFKNLJ610VP2 Unit base: RFE0132 For U.S.A. ≥1 Pair of stereo headphones:L0BAD0000164For Canada ≥1 Pair of stereo earphones:L0BAB0000182 ≥1 Pair of stereo headphones:L0BAD0000165 ≥1 Wired remote control:N2QCBD000011 ≥1 Jogger soft case:RFC0081-K ≥2 Alkaline batteries ≥1 Pair of stereo headphones:L0BAD0000164 SL-SV570 SL-SV573J SL-J610V Check the packing carton for these accessories. Use numbers indicated when ordering replacements or optional accessories from your Panasonic dealer. In U.S.A. to order accessories, refer to Accessory Purchases on page 4. Tuning mode selection Tuner on/ Band selection Display panel Plug type: 3.5 mm ( 1/8in.) stereo Noise may occur when using the car power adaptor and listening to the radio. Earphones: for Canada SL-J610V Headphones: for U.S.A. SL-SV570 SL-SV573J SL-J610V Turn off this unit and the other equipment before connection. References to the remote control apply only to SL-SV573J. Supplied Accessories Play/Stop/Turn offVolume control Hold switch Tuning/ Skip/ SearchTuner on/off/ Band selection Plug type: 3.5 mm ( 1/8in.) stereo ∫Using jogger soft case SL-SV573J ∫Using headphones ≥Before jogging with this unit, allow sufficient time for the memory buffer to fill up completely (CD-DA: 45 seconds, MP3: 100 seconds). ≥This unit is designed for light jogging, but not for serious running. It may occasionally skip if used by an aggressive runner, or by someone with a heavy, jarring stride. ≥Do not machine wash. Fading and loss of shape can occur. ≥Do not drop the unit as the soft case cannot protect the unit and CD from damage. Fasten the belt securely. Insert so buttons are facing away from your body. ≥Set the units volume to 10-15. ≥Use the main unit to avoid beep sounds heard when operating the remote control buttons. SL-SV573J Through to headphone jack (Ë) SL-SV573J Directly to headphone jack (Ë) SL-SV570 SL-J610V Connect the remote control to the main unit first. SL-SV573J SL-SV573J ≥Set the units volume to 10-15.
Page 2
3 IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturers instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet. 10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the apparatus. 11) Only use attachments/accessories specified by the manufacturer. 12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over. 13) Unplug this apparatus during lightning storms or when unused for long periods of time. 14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the applicable safety instructions listed below. Keep these operating instructions handy for future reference. ≥Discontinue use if you experience discomfort with the earphones or any other parts that directly contact your skin. Continued use may cause rashes or other allergic reactions. ≥Do not use in the car when the unit is connected to the speakers. ∫Batteries≥Do not peel off the covering on the batteries and do not use if the covering has been peeled off. ≥Align the poles iand jcorrectly when inserting the batteries. ≥Do not mix different types of batteries or old and new batteries. ≥Remove the batteries if you do not intend to use the unit for a long time. ≥Do not throw into a fire, short-circuit, disassemble, or subject to excessive heat. ≥Do not attempt to recharge dry cell batteries. ≥When carrying batteries in a pocket or bag, ensure no metal objects such as necklaces are placed together with them. Contact with metal may cause short-circuiting which can cause a fire. ∫CDs≥Do not use irregularly shaped CDs. ≥Do not use non-specification discs. ≥Do not use CDs printed with label printers available on the market. ≥Do not use CDs with labels and stickers that are coming off or with adhesive exuding from under labels and stickers. ∫Listening Do not play your headphones or earphones at a high volume. Hearing experts advise against continuous extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Do not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many areas. You should use extreme caution or temporarily discontinue use in potentially hazardous situations. Even if your headphones or earphones are the open-air type designed to let you hear outside sounds, dont turn up the volume so high that you cant hear whats around you. Sound can be deceiving. Over time your hearing comfort level adapts to higher volumes of sound. So what sounds normal can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level: ≥Start your volume control at a low setting. ≥Slowly increase the sound until you can hear it comfortably and clearly, and without distortion. Once you have established a comfortable sound level: ≥Leave it there. EST. 1924 CD SECTION ∫CD-DA Sampling frequency: 44.1 kHz No. of channels: 2 (left and right, stereo) Headphone output level: RMS max. 6 mWi6 mW/ 16 ≠(adjustable) Frequency response: 20 Hz to 20,000 Hz (0 dB to j3.5 dB) ONLY Speaker output level: RMS max. 450 mWi450 mW ∫MP3Supported bit-rates: 32 kbps to 320 kbps (128 kbps is recommended) Supported sampling frequency: 48 kHz/44.1 kHz/32 kHz Maximum number of items (total no. of albums and tracks): 999 Maximum album levels: 100 ∫PickupLight source: Semiconductor laser Wavelength: 780 nm RADIO SECTION ∫Frequency Radio frequency: FM; 87.90–107.90 MHz (0.2 MHz steps) 87.50–108.00 MHz (0.1 MHz/0.05 MHz steps) AM; 520–1710 kHz (10 kHz steps) 522–1629 kHz (9 kHz steps) SL-J610V Specifications AC adaptor power consumed in standby mode: 1.9 W References to battery recharging apply only to SL-J610V. Batteries used 2 alkaline batteries 2 optional rechargeable batteriesSL-J610V MP3disc 75 34CD-DA disc 33 16RADIO (FM BAND) 75 30 Caution GENERALPower supply: DC input (via included AC adaptor): DC 4.5 V AC adaptor input: AC 120 V, 60 Hz DC input (AC adaptor, not included): DC 4.5 V Operational temperature range: 0 eC–40 eC (32 eF–104 eF) ONLY Rechargeable temperature range: 5 eC–40 eC (41 eF–104 eF) Recharging time: About 4 to 5 hours Power consumption: Using AC adaptor: Using headphones/earphones (MP3/CD-DA/RADIO): 3.1 W/2.9 W/2.1 W Using speakers (MP3/CD-DA/RADIO):6.5 W/6.4 W/3.6 W Recharging: Without speakers : 5.4 W With speakers : 5.9 WPlay time: Using on a flat stable surface at 25 eC (77 eF) , S-XBS is off, Hold is on, Anti- skip is on POS 1 (CD-DA), recommended bit rate (MP3:128 kbps), and Digital Re-master is off (MP3). Play times are in hours and approximate. ≥The play time may be less depending on the operating conditions. ≥Play time will be considerably reduced when playing CD-RW. Dimensions (WaHaD): CD player : 135a26a135 mm (5 5/16za1 1/32za5 5/16z) ONLY Active speaker system: 135.5a286a185 mm (5 11/32za11 1/4za7 9/32z) Mass: CD player :227 g(8.0 oz.)(with batteries) 181 g(6.4 oz.)(without batteries) ONLY Active speaker system: 402 g(14.2 oz.) Note: Specifications are subject to change without notice. Mass and dimensions are approximate. SL-J610V SL-J610V SL-J610V SL-SV570 SL-SV573J SL-J610V
