Extracted text from panasonic sl j 600 v owners manual (Ocr-read)
Page 1
Main unit Remote control A Location of controls/Connection to other equipment Turn off this unit and the other equipment before connection. Battery compartmentHold switch Headphone jack Open switch Tuning/Skip/Search Play/Pause Stop / Operation off Volume control To DC IN jack Play/Stop/ Operation off Tuning/ Skip/Search Monaural/Stereo Sensitivity control/Play mode selection Memory/ Recall Audio system Adjust the volume on the audio system. AC adaptor Purchase (RP-AC46)for . SL-SV550 SL-SV553J Household AC outlet Car power adaptor (SH-CDC9) (not included) You can recharge the batteries with this connection. SL-J600V Car audio Hold switch Playing MP3 This unit can play MP3 files you have recorded to discs. MPEG Layer-3 audio decoding technology licenced from Fraunhofer IIS and Thomson multimedia. HOLD This function causes the unit to ignore accidental button presses. Set to HOLD so the unit doesnt power on accidentally or play is interrupted. ∫The unit and remote control each have independent HOLD switches. Note on CD-R and CD-RW This unit can play CD-R and CD-RW recorded with CD-DA or MP3. Use an audio recording disc for CD-DA and finalize §it when you finish recording. The unit may not be able to play some discs due to the condition of the recording. §A process performed after recording that enables CD- R/CD-RW players to play audio CD-R and CD-RW. Resume function The unit stores the track where you stopped play. Replacing the disc cancels the function. Auto power off function If the unit is left in stop mode for approximately 10 minutes, the unit powers itself off automatically. To CD or AUX terminals Audio cable (not included) Car stereo cassette adaptor(SH-CDM10A) (not included ) Set the units volume to 10. Tone selection ≥Set the units volume to 10. ≥Use the main unit to avoid beep sounds heard when operating the remote control buttons.Some cannot be connected. 2 Lens Supplied Accessories ONLY For U.S.A. ≥1 Pair of stereo headphones: L0BAD0000162 For Canada ≥1 Pair of stereo earphones: L0BAB0000123 ONLY ≥1 Wired remote control: N2QCBD000011 ≥1 Pair of stereo headphones: RFEV042P-SY ≥1 Jogger soft case: RFC0060-K SL-SV553J SL-SV550 SL-J600VCheck the packing carton for these accessories. Use numbers indicated when ordering replacements or optional accessories from your Panasonic dealer.In U.S.A. contact 1-800-332-5368 or the website (http://www.panasonic.com). Tuner on/off/Band selectVolume control Tuning mode selection Tuner on/Band selection For Canada Through to Headphone jack SL-SV553J Directly to headphone jack SL-SV550 SL-J600V Connect remote control to main unit first. For U.S.A. Actual headphones may be different from those shown in the illustration. Display panel ONLY ∫Using jogger soft case SL-SV553J ONLY ∫Using headphones SL-SV553J ≥ Before jogging with this unit, allow sufficient time for the memory buffer to fill up completely (CD-DA: 45 seconds, MP3: 100 seconds). ≥ This unit is designed for light jogging, but not for serious running. It may occasionally skip if used by an aggressive runner, or by someone with a heavy, jarring stride. ≥ Do not machine wash. Fading and loss of shape can occur. ≥ Do not drop the unit as the soft case cannot protect the unit and CD from damage.Fasten the belt securely. Insert so buttons are facing away from your body. SL-J600V SL-SV550 SL-SV553J SL-SV553J SL-SV553J ONLY ≥1 AC adaptor: RFEA403C-2S ≥1 Active speaker system (2 speakers and 1 unit base):RAPT0001-S SL-J600V
Page 2
3 Specifications ≥Discontinue use if you experience discomfort with the earphones or any other parts that directly contact your skin. Continued use may cause rashes or other allergic reactions. ≥Do not use in the car when the unit is connected to the speakers. ∫Batteries≥Do not peel off the covering on batteries and do not use if the covering has been peeled off. ≥Align the poles + and - correctly when inserting the batteries. ≥Do not mix different types of batteries or old and new batteries. ≥Remove the batteries if you do not intend to use the unit for a long time. ≥Do not throw into fire, short-circuit, disassemble, or subject to excessive heat. ≥Do not attempt to recharge dry cell batteries. ≥ When carrying batteries in a pocket or bag, ensure no metal objects such as necklaces are placed together with them. Contact with metal may cause short-circuiting which can cause a fire. ∫CDs≥Do not use irregularly shaped CDs. ≥Do not use non-specification discs. ≥Do not use CDs printed with label printers available on the market. ≥Do not use CDs with labels and stickers that are coming off or with adhesive exuding from under labels and stickers. ∫Listening Do not play your headphones or earphones at a high volume. Hearing experts advise against continuous extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Do not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many areas.You should use extreme caution or temporarily discontinue use in potentially hazardous situations.Even if your headphones or earphones are the open-air type designed to let you hear outside sounds, dont turn up the volume so high that you cant hear whats around you. Sound can be deceiving. Over time your hearing comfort level adapts to higher volumes of sound. So what sounds normal can actually be loud and harmful to your hearing. Guard against this by setting your equipment at a safe level BEFORE your hearing adapts. To establish a safe level: ≥Start your volume control at a low setting. ≥ Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.Once you have established a comfortable sound level: ≥Leave it there. EST. 1924 Batteries used 2 optional alkaline batteries 2 optional rechargeablebatteries SL-J600V MP3disc 35 14 CD-DA disc 23 10 RADIO (FM BAND) 75 30 References to battery recharging apply only to SL-J600V. Power consumption in standby mode:Without speakers : 2.1 W With speakers : 2.8 W IMPORTANT SAFETY INSTRUCTIONS Caution 1.Power source-Connect the unit to a power source of the type described in these instructions or as marked on the unit. 2. Polarization-The unit is equipped with a polarized power plug where one blade is wider than the other. This safety feature ensures that the plug fits into your household AC outlet only one way. If the plug doesnt fit one way, try reversing it. If the plug still doesnt fit, contact an electrician to replace the obsolete outlet. Do not attempt to defeat the safety purpose of the plug. 3. Power cord protection-Route the AC power supply cord so that it will not be walked on or pinched by items placed on or against it. Never take hold of the plug or cord with wet hands. Always grasp the plug body firmly when connecting and disconnecting it. 4. Overloading-When connecting the AC power supply cord, be careful not to overload the household AC outlet, extension cord, or outlet from any other device as this can result in fire or electric shock. 5.Nonuse periods-Turn the unit off when it is not in use. Unplug the unit from the household AC outlet if it is not to be used for a long time. Unplug the unit during lightning storms. Leaving the unit connected to a household AC outlet for extended periods can cause battery fluid leakage. 6. Attachments and accessories-Use only the attachments and accessories recommended in these operating instructions. ∫Placement1. Foreign material-Ensure objects and liquids do not get into the unit. Avoid exposing the unit to excessive smoke, dust, mechanical vibration, and shock. 2. Magnetism- Situate the unit away from equipment and devices that generate strong magnetic fields. 3. Stacking-Do not place anything on top of this unit. 4. Wall and ceiling mounting-Do not mount the unit on walls or ceilings unless specified in the instructions. ∫Environment1. Water and moisture-Do not use the unit near water, such as near a bathtub or swimming pool. Avoid damp basements. 2. Heat- Situate the unit away from heat sources, such as radiators. Do not leave it in an automobile exposed to direct sunlight with the doors and windows closed as this may deform the cabinet. 2.Do not situate where temperatures fall below 5 eC (41 eF) or rise above 35 eC (95 eF). Unplug the unit from the household AC outlet before cleaning. Clean with a damp cloth. Do not use abrasive pads, scouring powders, or solvents. 1. Damage requiring service-The unit should be serviced by qualified service personnel if: 1.(a) The AC power supply cord or AC adaptor has been damaged; or 1.(b) Objects or liquids have gotten into the unit; or 1.(c) The unit has been exposed to rain; or 1.(d) The unit does not operate normally or exhibits a marked change in performance; or 1.(e) The unit has been dropped or the cabinet damaged. 2. Servicing-Do not attempt to service the unit beyond that described in these operating instructions. Refer all other servicing to authorized servicing personnel. 3. Replacement parts-When parts need replacing ensure the servicer uses parts specified by the manufacturer or parts that have the same characteristics as the original parts. Unauthorized substitutes may result in fire, electric shock, or other hazards. 4.Safety check-After repairs or service, ask the servicer to perform safety checks to confirm that the unit is in proper working condition. Safety Installation Maintenance Service Read these operating instructions carefully before using the unit. Follow the safety instructions on the unit and the safety precautions listed below. Keep these operating instructions handy for future reference. CD SECTION ∫CD-DA No. of channels: 2 (left and right, stereo) Frequency response: 20 to 20,000 Hz (j10 dB to 0 dB) DA converter: 1 bit, MASH Headphone output level: RMS max. 8 mWi8 mW/ 16 ≠(adjustable) ONLY Speaker output level: RMS max. 450 mWi450 mW ∫MP3Supported bit-rates: 32 kbps to 320 kbps (128 kbps is recommended) Supported sampling frequency: 48 kHz/44.1 kHz/32 kHz Maximum number of items (sum of albums and tracks): 999 Maximum album levels: 100 ∫PickupLight source: Semiconductor laser Wavelength: 780 nm RADIO SECTION ∫Frequency Radio frequency: FM; 87.90–107.90 MHz (0.2 MHz steps) 87.50–108.00 MHz (0.1 MHz/0.05 MHz steps) AM; 520–1710 kHz (10 kHz steps) 522–1629 kHz (9 kHz steps) SL-J600V GENERALPower supply: DC input (via included AC adaptor): DC 4.5 VAC adaptor input: AC 120 V, 60 Hz DC input (via optional AC adaptor):DC 4.5 VOperational temperature range: 0 eC–40 eC (32 eF–104 eF) ONLY Rechargeable temperature range: 5 eC–40 eC (41 eF–104 eF) Recharging time: 4 to 5 hours Power consumption: Using AC adaptor:Using headphones/earphones (MP3/CD-DA/RADIO): 3.1 W/ 2.9 W/ 2.1 W Using speakers (MP3/CD-DA/RADIO):6.5 W/ 6.4 W/ 3.6 W Recharging: Without speakers : 5.4 W With speakers : 5.9 WPlay time: [Approximate operating time in hours (playing MP3 at the recommended bitrate of 128 kbps, with HOLD on and S-XBS canceled, at 25 eC (77 eF) on a flat and stable surface)] ≥The play time may be less depending on the operating conditions. ≥Play time will be considerably reduced when playing CD-RW. Dimensions (WaHaD): CD player : 135a25.8a135 mm (5 5/16za1 1/32za5 5/16z) Including components (SL-J600V ONLY):135.5a286a185 mm (5 11/32za11 8/32za7 9/32z) Mass: CD player :223 g(7.9 oz.)(with batteries) 177 g(6.2 oz.)(without batteries) Including components (SL-J600V ONLY): 391 g(13.8 oz.) Note:Specifications are subject to change without notice.Mass and dimensions are approximate. SL-J600V SL-SV550 SL-SV553J SL-J600V
