Panasonic sl ct 830 ee service manual
This is the 33 pages manual for panasonic sl ct 830 ee service manual.
Read or download the pdf for free. If you want to contribute, please upload pdfs to audioservicemanuals.wetransfer.com.
Extracted text from panasonic sl ct 830 ee service manual (Ocr-read)
Page 1
2 TABLE OF CONTENTS PA G E PA G E 1 Safety Precaution-------------------------------------------------3 1.1. Precaution of Laser Diode ------------------------------- 3 1.2. Handling Precautions for Traverse Deck ------------- 4 1.3. Supply of Rechargeable Battery as Replacement Parts ---------------------------------------- 5 1.4. Caution in use of Rechargeable Battery ------------- 5 2 Service Navigation------------------------------------------------6 2.1. General Description About Lead Free Solder (PbF) ---------------------------------------------------------- 6 3 Specifications------------------------------------------------------6 4 Location of Controls and Components--------------------7 4.1. Accessories -------------------------------------------------- 7 4.2. Location of Controls --------------------------------------- 7 5 Service Mode-------------------------------------------------------7 5.1. Display of Self-Diagnostic Function -------------------7 6 Troubleshooting Guide------------------------------------------8 6.1. Checking the Operation Problems on the Traverse Deck (Optical Pick-up) ----------------------- 8 7 Disassembly and Assembly Instructions-----------------9 7.1. Checking for the PCB -------------------------------------9 7.2. Replacement for the shaft angle, CD lid unit and shaft plate -------------------------------------------- 11 7.3. Replacement for the traverse motor----------------- 11 7.4. Replacement for the optical pick-up ----------------- 12 7.5. Replacement for the spindle motor ------------------ 13 8 Measurements and Adjustments--------------------------14 8.1. Automatic Adjustment Results Display Function (Self-Check Function) ---------------------- 14
Page 2
3 1 Safety Precaution 1.1. Precaution of Laser Diode
